Standards
  • IEEE 802.3
  • IEEE 802.3u
  • HomePlug AV

PowerLine interface
  • Power plug (country-dependent)

Ethernet interface
  • 10/100BASE-TX Ethernet port with Auto MDI/MDIX
  • RJ-45 connector

Input Power
  • 100V ~ 240V, 50/60 Hz, 0.1A
  • 4 W maximum

PowerLine modulation scheme
  • OFDM symbol modulation

PowerLine frequency band
  • 2 MHz to 30 MHz

Data rates
  • PowerLine: up to 200 Mbps (PHY rate)
  • Ethernet: 10/100 Mbps (autonegotiation)

Security
  • 128-bit AES link encryption

Minimum system requirements (For PC Utility Software)
  • Windows 7/Vista/XP SP3
  • Ethernet interface (100 Mbps)

LEDs
  • Power
  • PowerLine
  • LAN

Dimensions (L x W x H)
  • 61 x 42.4 x 68 mm

Weight
  • 125.6 g

Operating temperature
  • 0 to 40 ºC

Operating humidity
  • 10% to 90% non-condensing

Certifications
  • FCC
  • CE EMC Class B
  • UL
  • CE LVD
