Product Status - Live

What does this mean?

DWC-1000 - Revision A

Hardware revisions
Downloads can vary across product revisions.
Find my revision

Quick Links

Firmware
Do NOT upgrade firmware on any D-Link product over a wireless connection. Failure of the device may result. Use only hard-wired network connections.
Version Description Date
Download 4.2.0.3

Firmware

Please see the release note for further information

 30.4.2013.
Download
Additional Downloads
Version Description Date
Download A1
CE Declaration ver A1 - (English, French, Spanish, Portuguese)
 8.12.2011.
Download
Download
Guest management feature configuration guide
 30.4.2013.
Download
Download
AP profile configuration guide
 30.4.2013.
Download
Download
Captive portal feature configuration guide
 30.4.2013.
Download
Download
IPSec VPN tunnel configuration guide
 30.4.2013.
Download
Download
Layer 2 (L2) discovery configuration guide
 30.4.2013.
Download
Download
Layer 3 (L3) discovery configuration guide
 30.4.2013.
Download
Download
Additional access points support and VPN/firewall/advanced routing license activation guide
 30.4.2013.
Download
Download
WLAN client MAC authentication configuration guide
 30.4.2013.
Download
Datasheets
Description Type File Size
Download
Datasheet (English)
 PDF 2.72mb
Download
Download
IP Surveillance Product Guide
 PDF 27.68mb
Download
Download
Storage Product Guide
 PDF 25.32mb
Download
Manuals
Description Type File Size
Download
Manual (English)
 PDF 4.47mb
Download
Download
CLI Manual (English)
 PDF 1.70mb
Download
Quick Installation Guides
Version Description Date Type File Size
Download
Quick Installation Guide (English)
 PDF 1.13mb
Download
Interfaces
  • 4x Gigabit LAN ports
  • 2x Gigabit option ports3
  • 2x USB 2.0 ports
  • 1x Console (RJ-45) port

Capacity and performance
  • Default/maximum1 APs per unit: 6/24
  • Default/maximum1 APs per cluster: 24/96
  • Concurrent Captive Portal authentication users (wired/wireless): 124/400
  • Dedicated IPSec VPN tunnels: 70
  • Dedicated PPTP/L2TP VPN tunnels: 25
  • Dedicated SSL VPN tunnels: 20

Compatible Access Points
  • DWL-2600AP
  • DWL-3600AP
  • DWL-6600AP
  • DWL-8600AP

AP discovery & control
  • Layer 2
  • Layer 3

AP monitoring
  • Managed AP
  • Rogue AP
  • Authentication fail AP
  • Standalone AP

Client monitoring
  • Authenticated client
  • Rogue client
  • Authentication fail client
  • Ad-hoc client

Centralised management
  • RF channel pattern
  • RF power output
  • Security policy

Roaming
  • Fast roaming
  • Intra/inter-controlling roaming
  • Intra/inter-subnet roaming

Wireless security
  • WEP
  • Dynamic WEP
  • WPA Personal/Enterprise
  • WPA2 Personal/Enterprise

LAN security
  • 802.1x port-based access control
  • Guest VLAN

Wireless Intrusion Detection & Prevention System (WIDS)
  • Rogue/Valid AP classification
  • Rogue AP mitigation

Authentication
  • Captive portal
  • Guest management4
  • MAC authentication

VLAN
  • VLAN group: up to 255 entries
  • 802.1q VLAN
  • Subnet-based VLAN
  • Port-based VLAN

Firewall system2
  • Policy: 100 rules per feature, up to 600 rules total
  • Dynamic routing: RIPv1, RIPv2
  • Dynamic DNS
  • NAT/PAT
  • Web content filtering (Static URL/Keywords)

Networking2
  • Route failover
  • Outbound load balancing

Virtual Private Network (VPN) 2
  • Encryption: DES, 3DES, AES, Twofish, Blowfish, CAST-128, NULL
  • IPSec NAT Traversal
  • Dead Peer Detection
  • IP Encapsulating Security Payload (ESP)
  • IP Authentication Header (AH)
  • VPN Tunnel Keep Alive
  • Hub and Spoke

SSL Virtual Private Network (SSL VPN) 2
  • Encryption: DES, 3DES, AES
  • Message integrity: MD5, SHA1

System management
  • Web based user interface (HTTP)
  • Command line interface (CLI)
  • SNMP v1, v2c, v3

Physical and environmental
  • Internal power supply: DC 12V/2.5A
  • Max. Power Consumption: 19.3 W
  • Dimensions: 280 x 180 x 44 mm (W x L x H)
  • Weight: 1.7 Kg.
  • Operation Temperature: 0 to 40 °C
  • Storage Temperature: -20 to 70 °C
  • Operation Humidity: 5% to 95%, Non-condensing

Certifications
  • FCC Class B
  • CE Class B
  • VCCI
  • C-tick
  • IC
  • cUL, LVD (EN60950-1)

1 The number of managed APs can be increased by purchasing additional DWC-1000-6AP-LIC licenses
2 Feature enabled by purchasing the DWC-1000-VPN-LIC license
3 The first port is enabled by default. The second port is enabled by purchasing the DWC-1000-VPN-LIC license
4 Supported on firmware 4.2.0.3 or later. Please refer to the configuration guide available in the download section for DWC-1000 for more information.
