Wireless N Dual-Band PoE Outdoor Access Point

DAP-3520

  • Termék Státusz: End of Life

Connect wirelessly with speeds of up to 300 Mbps using the Wireless N (802.11n standard). The DAP-3520 provides the option to switch between 2.4 GHz and 5 GHz bands, giving more flexibility when setting up and optimising your wireless network. It is also fully backwards compatible with legacy 802.11a/b/g devices that work with either 2.4 GHz or 5 GHz bands.

Designed to handle a wide variety of outdoor environments, the DAP-3520 has a die-cast watertight housing with built-in heater and temperature sensor. Supporting 802.3af Power over Ethernet (PoE), it can be deployed in outdoor locations where power outlets are not easily accessible.

The DAP-3520 supports 64/128-bit WEP as well as WPA/WPA2 data encryption. MAC address filtering and ability to hide SSID, controls user access and further ensures no unwanted connection to your wireless network.

The DAP-3520 supports up to 4 SSIDs, allowing the administrators to logically divide the access point into several virtual access points all within a single hardware platform. Rather than having separate networks with several access points, administrators can deploy one single AP to support more than one application, such as public Internet access and internal network control to increase flexibility and keep costs down.

The DAP-3520 also supports AP grouping, allowing several access points to balance wireless network traffic and wireless clients among the AP with the same SSID and different non-overlapping frequency channels. This provides both scalability and optimisation of the wireless network.

Type
Software Managed AP
Wireless standard
Wireless N
Frequency band mode
Dual-band selectable
Antenna type
Embedded omni-directional antennas
Antenna gain
10 dBi for 5 GHz
8 dBi for 2.4 GHz
Power-over-Ethernet
Yes
Wired interface
1 x Gigabit Ethernet LAN
Indoor/outdoor
Outdoor
Type of housing
Metal
IP rating
IP65
Wireless modes
Access Point (AP)
WDS bridge
WDS with AP
Wireless client
Advanced features
MIMO
Maximum number of SSIDs
4
Auto channel selection
Supported
WMM-PS/802.11e (U-APSD)
Supported
Wi-Fi scheduler
Supported
AP traffic load balance
Supported
L2 roaming
Supported
WEP 64/128 bit
Supported
WPA/WPA2-Personal/Enterprise
Supported
TKIP/AES encryption
Supported
WPA_WPA2_PSK over WDS
Supported
WLAN partition
Supported
SSID broadcast disable
Supported
Rogue AP detection
Supported
Station isolation
Supported
MAC address filtering
Supported
802.1X authentication
Supported
DHCP server
Supported
802.1D STP
Supported
IGMP snooping
Supported
ARP spoofing
Supported
NTP
Supported
WEB
Supported
SNMP (v1, v2c, v3)
Supported
CLI
Supported
Telnet
Supported
SSH
Supported
Syslog
Supported
Central management (through AP Manager II and/or D-View Wireless Control Module)
Supported
This product was phased out on: 11/07/2015
This product's last date of support is on: 09/07/2020
