The D-Link® Wireless N Pocket Router/Access Point (DAP-1350) features multi-mode functionality you can utilize as a wireless router to create an 11n Wi-Fi network or easily use as an access point to add Wi-Fi to an existing wired network to provide a wireless connection anywhere desired. The DAP-1350 also functions as a wireless client to easily connect an Ethernet-ready device (such as a desktop PC or Xbox 360®) to a Wi-Fi network for increased flexibility and added convenience for your wireless networking needs.
The Wireless Router That Travels
Compact and lightweight, the DAP-1350 is small enough to carry with you while traveling and sets up easily. Use the DAP-1350 to easily share an Internet connection or connect to an existing wired network in conference rooms, hotel rooms, or anywhere a Wi-Fi network is needed. Equipped with a travel case, the compact and lightweight DAP-1350 is the perfect companion for all your business and personal travels.
Advanced Wireless Security
The DAP-1350 supports the latest wireless security features to help prevent unauthorized access, be it from over a wireless network or the Internet. Support for WPA™ and WPA2™ ensure that you will be able to use the best possible encryption regardless of your client devices.
Delivering powerful 11n performance with multi-mode functionality and increased mobility, the DAP-1350 is an ideal solution for providing convenient wireless connectivity anywhere Wi-Fi access is needed.
What This Product Does
Use the Wireless N Pocket Router/Access Point to create a Wi-Fi network anywhere wireless is needed. It can also be used to connect an Ethernet-ready device (such as a desktop PC or Xbox 360®) to a Wi-Fi network.
Why Wireless N Is Better
This Wireless N Pocket Router/Access Point uses Wireless N technology with multiple intelligent antennas to maximize the speed and range of your wireless signal to significantly outperform previous-generation Wireless G devices1. The internal antennas bounce multiple wireless signals off walls and ceilings to work around obstructions and help eliminate dead spots.
Wireless N Pocket Router Benefits
- Multi-mode functionality with wireless router, access point, or wireless client mode
- Create a powerful Wi-Fi network with Wireless N technology
- Backward compatible with Wireless G devices
- SharePort™ Technology for sharing a USB printer or storage over your network2
- Supports Power over USB allowing a PC to power the DAP-1350 if AC power is not accessible3
- Easily add devices and secure your network with push button security
- Secure your wireless network using advanced WPA™ or WPA2™ encryption
1 Maximum wireless signal rate derived from IEEE Standard 802.11 specifications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate. Environmental factors will adversely affect wireless signal range. Wireless range and speed rates are D-Link RELATIVE performance measurements based on the wireless range and speed rates of a standard Wireless G product from D-Link. Maximum throughput based on D-Link Wireless N devices.
2 SharePort support available in router mode only.
3 Power over USB requires direct connection to a PC’s USB port with a minimum output of 500mA.
Specs
Wireless standard
|
Wireless N |
---|---|
Wireless speed
|
300 Mbps 2.4 GHz |
Antenna type
|
Embedded omni-directional antennas |
Wired interface
|
1 x Fast Ethernet WAN 4 x Fast Ethernet LAN |
3G/4G LTE support
|
3G/4G LTE via optional USB dongle |
USB ports
|
1 x USB 2.0 |
Support
Version | Date | Type | File Size | |
---|---|---|---|---|
Datasheet (English) | - | 1.40mb | Letölt |
Version | Leírás | Date | Type | File Size | |
---|---|---|---|---|---|
Manual (English) | Manual (English) |
- | 9.34mb | Letölt |
Version | Leírás | Date | Type | File Size | |
---|---|---|---|---|---|
Quick Installation Quick (English) |
- | 0.77mb | Letölt |
http://tsd.dlink.com.tw/GPL.asp
Ezen termékben használt GPL és LGPL kódok GARANCIA NÉLKÜL lettek terjesztve, és azok egy vagy több szerző szerzői jogi védelme alatt állnak. Részletekért tekintse meg ezen termék GPL és LGPL kódját és a GPL és LGPL felhasználási feltételeit.
Version | Leírás | Date | |
---|---|---|---|
CE doc Revision A1 | CE document | 2009. 10. 27. | Letölt |
