Wireless AC Unified Services VPN Router
DSR-1000AC
- Product Status (Revision B): Live
Where to buy
The DSR-1000AC Wireless AC Unified Services VPN Router provides a secure, high-performance networking solutions to address the growing needs of small and medium businesses. Next generation wireless performance provides wireless speeds of up to 1300 Mbps.
![](/fi/fi/-/media/product-pages/dsr/1000ac/dsr1000ac_intro.jpg)
Comprehensive Management Capabilities
The DSR-1000AC includes dual WAN Gigabit Ethernet ports to provide high availability for your WAN or Internet connections. Traffic can be load-balanced across the links with Outbound Load Balancing, increasing the performance and availability of business applications. It supports mobile broadband networks via an optional USB modem1, such as 3G or 4G dongles.
![](/fi/fi/-/media/product-pages/dsr/1000ac/dsr1000ac_management.png)
Web Authentication Capabilities
Captive Portal allows employees and guest users to be easily authenticated and authorised by accessing a customised landing page. Users can be authenticated by a local database, RADIUS, LDAP, Microsoft Windows Active Directory, NT Domain and POP3 server. A maximum of four servers can be configured at any one time.
![](/fi/fi/-/media/product-pages/dsr/1000ac/dsr1000ac_authenticating.jpg)
Complete and Robust VPN Features
A fully featured virtual private network (VPN) provides your mobile workers and branch offices with a secure link to your network. The DSR-1000AC is capable of Secure Sockets Layer (SSL) VPN tunnels, as well as Generic Routing Encapsulation (GRE) tunnels, empowering your mobile users by providing remote access to a central corporate database. Site-to-site VPN tunnels use IP Security (IPSec) Protocol, Point-to-Point Tunneling Protocol (PPTP), or Layer 2 Tunneling Protocol (L2TP) to facilitate branch office connectivity through encrypted virtual links. OpenVPN allows mobile users to connect to the intranet via encrypted links with their PC, laptops or mobile devices.
![](/fi/fi/-/media/product-pages/dsr/1000ac/dsr1000ac_features.png)
Specs
Type
|
VPN security router |
---|---|
Wireless standard
|
Wireless AC |
Frequency band mode
|
Dual-band simultaneous |
Wireless speed
|
1300 Mbps 5 GHz 450 Mbps 2.4 GHz |
Antenna type
|
3 detachable omni-directional antennas |
Antenna gain
|
2 dBi for 2.4 GHz 2 dBi for 5 GHz |
Wired interface
|
2 x Gigabit Ethernet WAN 4 x Gigabit Ethernet LAN |
USB ports
|
2 x USB 2.0 |
Console port
|
Supported
|
Indoor/outdoor
|
Indoor |
Type of housing
|
Metal |
Wireless modes
|
Access Point (AP) |
Advanced features
|
MIMO |
Maximum number of SSIDs
|
4 |
WEP 64/128 bit
|
Supported
|
WPA/WPA2-Personal/Enterprise
|
Supported
|
TKIP/AES encryption
|
Supported
|
Firewall throughput
|
950 Mbps |
VPN throughput (3DES)
|
250 Mbps |
Concurrent sessions
|
100000 |
Firewall policies
|
600 |
Internet connection type
|
Multiple PPPoE PPPoE/L2TP/PPTP Static/Dynamic IP |
Firewall system
|
Dynamic DNS Dynamic route Inter-VLAN route Intrusion prevention system (IPS) NAT, PAT Static route Web content filtering |
Networking
|
3G redundancy DHCP relay DHCP server/client IEEE802.1q VLAN IP multicast IPv6 Outbound load balancing Route failover VLAN (port-based) |
VPN tunnels
|
195 |
IPSec tunnels
|
50 70 |
Encryption methods
|
DES, 3DES, AES, Twofish, Blowfish, CAST-128, NULL RC4-128, 3DES, AES |
VPN features
|
Dead Peer Detection Hub and Spoke IP Authentication Header (AH) IP Encapsulating Security Payload (ESP) IPSec NAT Traversal IPSec/PPTP/L2TP Server VPN Tunnel Keep Alive |
Bandwidth management
|
Port-based QoS |
WEB
|
Supported
|
SNMP (v1, v2c, v3)
|
Supported
|
CLI
|
Supported
|
