Downloads can vary across product revisions. Please select the correct hardware revision.

Powerline interface
  • Power plug (country/region-dependent)
Ethernet interface
  • 10/100BASE-TX Fast Ethernet ports with audio MDI/ MDIX
Standards
  • IEEE 802.3
  • IEEE 802.3u
  • HomePlug AV
  • IEEE 1901
Security
  • 128-bit AES data encryption
LEDs
  • Power
  • Powerline
  • Ethernet
Powerline modulation scheme
  • OFDM symbol modulation
Powerline frequency band
  • 2 to 28MHz
Data rate
  • Powerline: AV200
  • Ethernet: 10/100 Mbps (Auto-Negotiation)
Dimensions
  • 70 x 52 x 26 mm (2.76 x 2.05 x 1.02 inches)
Weight
  • 110.7g
Power
  • Input: 100 to 240 V AC
  • Maximum power consumption: 3.01 W
Power saving
  • Power-saving mode supported
  • Compliant with European Energy Using Product directive
Temperature
  • Operating: 0 to 40°C (32 to 104°F)
  • Storage: -10 to 70°C (14 to 158°F)
Humidity
  • Operating: 10% to 90% non-condensing
  • Storage: 5% to 90% non-condensing
Certifications
  • FCC
  • CE LVD
  • UL
  • CE EMC Class B

1Maximum throughput is based on theoretical transmission PHY rate. Actual data throughput will vary. Network conditions and environmental factors, including volume of traffic and network overhead, may lower actual data throughput rate. Interference from devices that emit electrical noise, such as vacuum cleaners and hair dryers, may adversely affect the performance of this product. This product may interfere with devices such as lighting systems that have a dimmer switch or a touch-sensitive on/off feature, short wave radios, or other Powerline devices that do not follow the HomePlug AV standard.
