Network Standards
  • IEEE: 802.3 Ethernet, 802.3u Fast Ethernet
  • IEEE 802.3x Flow control
  • IEEE 802.3af Power over Ethernet

Device Interfaces
  • 4RJ-45 10/100BASE-TX ports with 802.3af PoE
  • 4RJ-45 10/100BASE-TX ports without 802.3af PoE
  • Power adapter socket

Performance
  • MAC Address Table: 1K
  • Switch Fabric: 1.6Gps
  • Transmission Method: Store-and-forward
  • Packet Buffer Memory: 96KB

Diagnostic LEDS
  • Per Unit Power/PoE Max
  • Per Port: Activity/Link & Speed
  • PoE port: Power/Status

Electrical
  • Power Supply: 48V DC/1.45A (through external power adapter)
  • Max Power Consumption: 62.3 Watts max
  • PoE budget: Up to 15.4 Watts max per port (for ports 1 to Port 4 only), 56 Watts total

Temperature
  • Operating: 0 - 40 degress C (32 - 104 degrees F)
  • Storage: 10 - 70 degrees C (14 - 158 degrees F)

Operating Humidity
  • 10% - 95% RH non-condensing

Storage Humidity
  • 5% - 90% non-condensing

Dimensions
  • 171 (W) x 98 (D) x 29 (H) mm
  • (6.73 x 3.86 x 1.14 inches)

Weight
  • 454 grams (1lb)

Certifications
  • FCC Class B
  • CE
  • VCCI

Safety
  • LVD
