Vigilance Full HD Panoramic PoE Camera

DCS-4622

Share

Professional.
Simple.
Affordable.

The all-seeing-eye that gives you 360° coverage that captures it all.

Fisheye lens · Hhigh-resolution 3-megapixel sensor · Distortion correction

The Vigilance Camera Range offers professional video surveillance that is easy to install and highly affordable.

Features

D-Link DCS-4622 Vigilance Full HD Panoramic PoE Camera
Full HD 3MP Video
Crisp, clear recording and playback so you never have to wonder
D-Link DCS-4622 Vigilance Full HD Panoramic PoE Camera
2 Way audio
2-way audio with built-in microphone and speaker
D-Link DCS-4622 Vigilance Full HD Panoramic PoE Camera
Night Vision
IR LEDs guarantee bright & clear images, even in total darkness
D-Link DCS-4622 Vigilance Full HD Panoramic PoE Camera
Motion Detection
Configure motion sensors and privacy mask settings so you always know what's happening
D-Link DCS-4622 Vigilance Full HD Panoramic PoE Camera
Wide Dynamic Range
Easily identify subjects in any lighting with digital WDR video enhancemen
D-Link DCS-4622 Vigilance Full HD Panoramic PoE Camera
Onboard SD Recording
Record snapshots and video to a microSD card without requiring a PC or network storage device
360° Surveillance

360° Surveillance

The DCS-4622 uses a fisheye lens to provide incredible wide angle coverage; simply place it on a wall for panoramic 180° wall-to-wall coverage of a room, or place it on a ceiling for a full 360° view without blind spots. Distortion correction fixes the camera video so you can use ePTZ to zoom in, zoom out and pan across your camera’s video to survey a large area with ease.

Security in High Definition

Crisp Full HD, 3 megapixel video gives you a clear view of what's going on. High definition resolution and a compact design makes the DCS-4622 Ideal for small, medium and large enterprise installations.

Security in High Definition

*Screen images simulated

Continuous Monitoring with Night Vision

Continuous Monitoring with Night Vision

Built-in IR LED illuminators automatically turn on depending on lighting conditions, allowing the camera to capture video even in low-light or no-light conditions.

Combined with the IR-Cut filter, the DCS-4622 can also provide sharp grayscale video in low-light conditions. Embedded with a powerful SoC (System-on-Chip), the camera provides real-time video compression in H.264 and MJPEG formats.

Motion Detection

Motion Detection

Motion detection lets you record events with ease and can even save snapshots and video before the event even happens so you can get the whole picture.

PoE = Convenience

PoE = Convenience

Power over Ethernet makes surveillance installation simpler, safer and less expensive. The DCS-4622 has a built-in 802.3af compliant PoE module, allowing for single cable deployment and reducing the need to drill holes or lay additional cabling.
*The DCS-4622 can also be powered by a standard 12V DC, 1.5A power adapter (not included).

Video Management Software (VMS)

Manage your cameras with the free VMS solution called D-ViewCam, a complete surveillance software package that enables you to view, manage and record up to 32 cameras on a single computer. In addition, the DCS-4622 is Onvif-compliant and supported by several VMS solutions to seamlessly integrate with other vendor IP cameras and NVRs.

Video Management Software (VMS)

Functions & Features

Features

Camera

  • 1/3.2” 3-megapixel CMOS progressive sensor
  • Fixed fisheye lens: 1.1 mm F2.0
  • Built-in microphone and speaker for 2-way communication
  • ONVIF compliant

Connections

  • 10/100 Fast Ethernet port with PoE support
  • microSD card slot for onboard storage2

Image & Video

  • High resolution video and snapshots, up to 1920 x 1536
  • Distortion correction
  • H.264 and Motion JPEG compression
  • Desktop, Wall, and Ceiling mount display modes
  • ePTZ viewing
  • Simultaneous multi-stream support
  • Supports multiple access lists
  • Built-in Samba client for saving to a NAS

Technical Specifications

Camera

Camera Hardware Profile

  • 1/3.2” 3 megapixel progressive CMOS sensor
  • 8 metre (25 feet) IR illumination distance
  • Minimum illumination:
    • Day Mode: 0.5 lux
    • Night Mode (LEDs off): 0.25 lux
    • Night Mode (LEDs on): 0 lux
  • Built-in Infrared-Cut Removable (ICR) Filter module
  • Focal length: 1.1 mm
  • Aperture: F2.0
  • Angle of view:
    • (H) 180°
    • (V) 180°
    • (D) 180°
  • Angle of adjustment:
    • (V) 15°
  • Minimum object distance: 0.3 m
  • Built-in microphone and speaker

Image Features

  • Configurable image size, quality, frame rate, and bit rate
  • Time stamp and text overlays
  • Flip and mirror
  • Configurable motion detection windows
  • Desktop, wall, and ceiling display modes
  • Configurable shutter speed, brightness, saturation, contrast, and sharpness
  • WDR
  • 3D filter

Display Modes

  • Fisheye View
  • Normal View
  • Multi-View with Panorama
  • Panoramic View
  • Mixed View (with Fisheye)
  • Multi View

Video Compression

  • Simultaneous H.264/MJPEG format compression
  • H.264/MJPEG multicast streaming
  • JPEG for still images

Video Resolution

  • 1920 x 1536, 1440 x 1152, 1280 x 1024, 960 x 768, 640 x 512 up to 25 fps1

Audio Support

  • G.711 AAC

External Device Interfaces

  • 10/100 BASE-TX Fast Ethernet port
  • Supports 802.3af PoE (Class 2)
  • microSD/SDHC/SDXC card slot, accepts cards up to 128 GB2

Network

Network Protocols

  • IPv4, IPv6, ARP, TCP, UDP, ICMP
  • DHCP client
  • NTP client (D-Link)
  • DNS client
  • SMTP client
  • DDNS client (D-Link)
  • SMTP client
  • FTP client
  • HTTP server
  • HTTPS for configuration
  • Samba client
  • PPPoE
  • UPnP port forwarding
  • RTP/RTSP/RTCP
  • IP filtering
  • QoS/DSCP
  • CoS
  • Multicast
  • SNMP
  • IGMP
  • ONVIF compliant
  • Bonjour

Security

  • Administrator and user group protection
  • Password authentication
  • HTTP and RTSP digest encryption

System Management

System Requirements for Web Interface

  • Browser: Internet Explorer, Firefox, or Safari

Event Management

  • Motion detection
  • Event notification and uploading of snapshots/video clips via e-mail or FTP
  • Take snapshots/video clips and save to integrated microSD card slot
  • Supports multiple SMTP and FTP servers
  • Multiple event notifications
  • Multiple recording methods for easy backup

Remote Management

  • Configuration interface accessible via web browser

D-ViewCam™ System Requirements

  • Operating System: Microsoft Windows 10/8/7/Vista
  • Web Browser: Internet Explorer 7 or higher
  • Protocol: Standard TCP/IP

D-ViewCam™ Software Functions

  • Remote management/control of up to 32 cameras
  • Viewing of up to 32 cameras on one screen
  • Supports all management functions in web interface
  • Scheduled motion triggered or manual recording options

Physical

Weight

  • 210 g ± 5%

External Power Adapter (not included)

  • Input: 100 to 240 V AC, 50/60 Hz
  • Output: 12 V DC, 1.5 A

Power Consumption

  • 4.6 watts max.

Temperature

  • Operating: 0 to 40 °C (32 to 104 °F)
  • Storage: -20 to 70 °C (-4 to 158 °F)

Humidity

  • Operating: 20% to 80% non-condensing
  • Storage: 5% to 95% non-condensing

Certifications

  • CE
  • CE LVD
  • FCC
  • C-Tick

Dimensions

  • Φ97 × 48.3mm
1. Frame rates when streaming video may vary depending on network conditions and method used.
2. microSD card not included. microSD/SDHC/SDXC v3.1 compatible.
