Wireless N Dual Band PoE Access Point

DAP-2590

  • Product Status: Phased Out

The DAP-2590 is second generation Dual Band Wireless N indoor access point designed specifically for businesses. It’s varied and comprehensive management capabilities ensures that the DAP-2590 meets the needs of almost any business.


Download de datasheet.

Alle Verkooppunten

Compatibility and performance

With adjustable antennas, the DAP-2590 delivers 300Mbps per band performance

Broadcast 16 independent SSIDs simultaneously

Supports up to 16 SSIDs, 8 per Band, including station isolation

Performance and Compatibility

The DAP-2590 is a second generation Dual-Band Wireless N indoor access point designed specifically for businesses. It’s varied and comprehensive management capabilities ensures that the DAP-2590 meets the needs of almost any business.

Simultaneous Dual-Band Wireless

Supports up to 300Mbps for the 5Ghz band and up to 300Mbps for the 2.4Ghz band

Smart Design

The DAP-2590 has a wireless scheduler feature, which turns off wireless functionality when it isn’t needed, saving power and increasing network security.

Web Smart 24-Port PoE 10/100 + (4) 1000BASE-T Ports + 2 Combo Ports Switch
Find out more
24-Port xStack Gigabit L2+ Stackable Managed PoE Switch
Find out more

Technical Specifications

Standards
  • IEEE Draft 2.0 802.11n
  • IEEE 802.11a
  • IEEE 802.11g
  • IEEE 802.3ab
  • IEEE 802.3af
  • IEEE 802.3u
  • IEEE 802.3

Network Management
  • Command Line Interface: Telnet / Secure (SSH) Telnet
  • Web Browser interface: HTTP / Secure HTTP (HTTPS)
  • SNMP Support: D-View Module / Private MIB
  • AP Manager II

Security
  • WPA™-Personal
  • WPA™-Enterprise
  • WPA2™-Personal
  • WPA2™-Enterprise
  • 64/128-bit WEP
  • SSID Broadcast Disable
  • MAC Address Access Control

Wireless Frequency Range
  • 2.4GHz (2.4GHz to 2.4835GHz)
  • 5GHz (5.15GHz to 5.35GHz, 5.47GHz to 5.85GHz)

Operating Modes
  • Access Point (AP)
  • WDS with AP
  • WDS/Bridge (No AP Broadcast)
  • Wireless Client

LEDs
  • Power
  • 5GHz
  • LAN
  • 2.4GHz

Operating Voltage
  • 48VDC +/- 10% for PoE or 5V2.5A

Temperature
  • Operating: 32°F to 104°F (0°C to 40°C)
  • Storing: -4°F to 149°F (-20°C to 65°C)

Humidity
  • Operating: 10% ~ 90% (Non-condensing)
  • Storing: 5% ~ 95% (Non-condensing)

Certifications
  • FCC
  • CE
  • C-Tick
  • IC
  • UL
  • Wi-Fi®

Weight
  • 762g

Dimensions (WxHxD)
  • 6.5” x 1.38” x 7.38”

FAQ

Versie Datum Type Bestandsgrootte
Datasheet (English) - PDF 4.47mb Download
Versie Beschrijving Datum Type Bestandsgrootte
Manual (English)

Manual (English)

- PDF 3.69mb Download
AP Manager II - User AP Manager II - User Manual (English) - PDF 5.96mb Download
Versie Beschrijving Datum Type Bestandsgrootte
Quick Installation Guide (Multilingual) - PDF 1.91mb Download
Dit D-Link product bevat software code welke ontwikkeld is door derden, waaronder software code die valt onder de GNU General Public License ("GPL") of GNU Lesser General Public License ("LGPL"). Indien van toepassing: de voorwaarden van de GPL en LGPL en informatie over het verkrijgen van toegang tot de GPL-code en LGPL-code die in dit product zijn gebruikt, zijn hier voor u beschikbaar:

http://tsd.dlink.com.tw/GPL.asp

De GPL-code en LGPL-code die gebruikt is in dit product wordt gedistribueerd ZONDER ENIGE GARANTIE en is onderworpen aan de auteursrechten van een of meer auteurs. Voor meer informatie, zie de GPL-code en de LGPL-code voor dit product en de voorwaarden van de GPL en LGPL.
Versie Beschrijving Datum
Firmware 1.25rc056

Firmware

15/05/2013 Download
Firmware 1.20 rc039 Firmware 26/07/2012 Download
Versie Beschrijving Datum
MIB file 1.15 rc012 MIB file 15/08/2011 Download
AP Manager II v 1.13 1.13 r38

AP Manager II v 1.13

Release notes enclosed.

6/01/2011 Download
Versie Beschrijving Datum
CE Declaration - ver A2 CE Declaration - ver A2 (English, French) 21/08/2009 Download
