Standards

  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 1901



Powerline interface

  • Power plug (country-dependent)



Ethernet interface

  • 10/100/1000BASE-TX Ethernet port with auto MDI/ MDIX
  • RJ-45 connector



PowerLine modulation scheme

  • OFDM Symbol Modulation



PowerLine frequency band

  • 2 MHz to 70 MHz



Data rate

  • Powerline: Up to 500 Mbps (PHY rate)
  • Ethernet: 10/100/1000 Mbps (autonegotiation)



QoS

  • Integrated QoS prioritises media and data



Security

  • 128-bit AES data encryption



Minimum system requirement (For PC Utility Software)

  • PC with 200 MHz processor
  • 64 MB memory
  • Windows 7, Vista, XP SP2
  • Ethernet interface (1000 Mbps)



LEDs

  • Power
  • Powerline
  • Ethernet



Power input

  • 100 to 240 V AC, 50/60 Hz



Power Saving

  • Power saving mode supported
  • Compliant with European Energy Using Product Directive



Dimensions

  • 156 x 69 x 42.5 mm. (each adapter)



Weight

  • 150 g. (each adapter)



Operating temperature

  • 0 to 40 ºC



Operating humidity

  • 10% to 90% non-condensing



Certifications

  • CE EMC Class B
  • CE LVD
