This product was phased out on:
6/09/2016
Downloads kunnen variëren per productrevisie. Vind mijn revisie

Camera hardware profile
  • Sony Super HAD-II 1/4” CCD sensor
  • 650 TVL resolution
  • Minimum illumination: 0.1 lux (Color), 0.01 lux (B/W)
  • Built-in Infrared-Cut Removable (ICR) filter module
  • Electronic shutter: 1 to 1/10000 second
  • S/N ratio > 50 dB (AGC off)
  • 12x optical zoom
  • Fixed length: 3.8 to 45.6 mm
  • Aperture: F1.6 to F2.7
  • Angle of view:
  • (H) 4.49° to 52.8°
  • (V) 3.40° to 39.7°
  • (D) 55.4° to 65.4°

PTZ hardware profile

  • Pan travel: 360° endless
  • Tilt travel: 10° to 170°
  • Manual speed: 1° to 80°/second
  • Presets: 256 points
  • Preset Accuracy: 0.225°
  • Preset Speed: 10° to 400°/second
  • Sequence Paths: 8
  • Auto Pan Paths: 4
  • Cruise Paths: 8
  • Pan and tilt speed proportional to zoom ratio
  • Resume after power loss
  • Home Functions: Preset, Sequence, Auto Pan, Cruise
  • Auto Flip: Mechanical/Digital/Off
  • Digital Slow Shutter
  • Image Freeze
  • Image Inverse

Image features
  • Configurable image size, quality, frame rate, and bit rate
  • Time stamp and text overlays
  • Configurable motion detection windows
  • 16 configurable privacy mask zones
  • Configurable white balance, shutter speed, brightness, saturation, contrast, and sharpness

Video compression
  • Simultaneous H.264/MPEG-4/MJPEG format compression
  • JPEG for still images
  • H.264/MPEG-4 multicast streaming

Video resolution
  • NTSC: 720 x 480, 352 x 240, 176 x 120 at up to 30 fps
  • PAL: 720 x 576, 352 x 288, 176 x 144 at up to 25 fps

Audio support
  • G.726

Device interfaces
  • 10/100 BASE-TX Ethernet port
  • 8 alarm inputs
  • 1 alarm output
  • Audio input/output
  • Video output

Network protocols
  • IPv4, TCP/IP, UDP, ICMP, DHCP Client, NTP Client (D-Link), DNS Client, DDNS Client (D-Link), SMTP Client, FTP Client, HTTP / HTTPS, Samba Client, PPPoE, UPnP Port Forwarding, RTP / RTSP/ RTCP, IP filtering, 3GPP, IGMP, ONVIF Compliant

Security
  • Administrator and user group protection
  • Password authentication
  • HTTP and RTSP digest encryption

System Requirements for Web Interface
  • Operating System: Microsoft Windows 7/Vista/XP/2000
  • Browser: Internet Explorer, Firefox, Netscape, Opera

Event management
  • Motion detection
  • Event notification and upload snapshots/video clips via HTTP, SMTP, or FTP
  • Supports multiple HTTP, SMTP, and FTP servers
  • Multiple event notifications
  • Multiple recording methods for easy backup

Remote management
  • Configuration accessible via web browser
  • Take snapshots/video clips and save to local hard drive or NAS via web browser

Mobile support
  • Handsets with 3GPP player (QuickTime 6.5, Real Player 10.5)

D-ViewCam™ System Requirements
  • Operating System: Microsoft Windows 7/Vista/XP
  • Web Browser: Internet Explorer 6 or higher
  • Protocol: Standard TCP/IP

D-ViewCam™ Software Functions
  • Remote management/control of up to 32 cameras
  • Viewing of up to 32 cameras on one screen
  • Supports all management functions provided in web interface
  • Scheduled motion triggered, or manual recording options

Power
  • Power Input DC 12 V/2 A
  • Max. Power Consumption 14 W

Enviromental
  • Operating Temperature 0 to 40 ˚C
  • Storage Temperature -20 to 70 °C
  • Humidity 20% to 80% non-condensing

Weight
  • 1.2 kg

Certifications
  • CE (Class A)
  • CE LVD (EN60965-1)
  • FCC (Class A)
  • ICES-003
  • C-Tick
