Wireless N Pocket Router & Access Point

DAP-1350

  • Product Status: Phased Out

Small enough to carry with you, the Wireless N Pocket Router and Access Point (DAP-1350) easily sets up to create a powerful 11n Wi-Fi network, making it the perfect travel companion for business or personal use. Delivering Wireless N performance with multi-mode functionality and increased mobility, the DAP-1350 provides convenient wireless connectivity anywhere Wi-Fi access is needed.


Download de datasheet.

Alle Verkooppunten
One Device, Three Wireless Functions
The D-Link® Wireless N Pocket Router/Access Point (DAP-1350) features multi-mode functionality you can utilize as a wireless router to create an 11n Wi-Fi network or easily use as an access point to add Wi-Fi to an existing wired network to provide a wireless connection anywhere desired. The DAP-1350 also functions as a wireless client to easily connect an Ethernet-ready device (such as a desktop PC or Xbox 360®) to a Wi-Fi network for increased flexibility and added convenience for your wireless networking needs.

The Wireless Router That Travels
Compact and lightweight, the DAP-1350 is small enough to carry with you while traveling and sets up easily. Use the DAP-1350 to easily share an Internet connection or connect to an existing wired network in conference rooms, hotel rooms, or anywhere a Wi-Fi network is needed. Equipped with a travel case, the compact and lightweight DAP-1350 is the perfect companion for all your business and personal travels.

Advanced Wireless Security
The DAP-1350 supports the latest wireless security features to help prevent unauthorized access, be it from over a wireless network or the Internet. Support for WPA™ and WPA2™ ensure that you will be able to use the best possible encryption regardless of your client devices.

Delivering powerful 11n performance with multi-mode functionality and increased mobility, the DAP-1350 is an ideal solution for providing convenient wireless connectivity anywhere Wi-Fi access is needed.

What This Product Does
Use the Wireless N Pocket Router/Access Point to create a Wi-Fi network anywhere wireless is needed. It can also be used to connect an Ethernet-ready device (such as a desktop PC or Xbox 360®) to a Wi-Fi network.

Why Wireless N Is Better
This Wireless N Pocket Router/Access Point uses Wireless N technology with multiple intelligent antennas to maximize the speed and range of your wireless signal to significantly outperform previous-generation Wireless G devices1. The internal antennas bounce multiple wireless signals off walls and ceilings to work around obstructions and help eliminate dead spots.

Wireless N Pocket Router Benefits
  • Multi-mode functionality with wireless router, access point, or wireless client mode
  • Create a powerful Wi-Fi network with Wireless N technology
  • Backward compatible with Wireless G devices
  • SharePort™ Technology for sharing a USB printer or storage over your network2
  • Supports Power over USB allowing a PC to power the DAP-1350 if AC power is not accessible3
  • Easily add devices and secure your network with push button security
  • Secure your wireless network using advanced WPA™ or WPA2™ encryption


1 Maximum wireless signal rate derived from IEEE Standard 802.11 specifications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate. Environmental factors will adversely affect wireless signal range. Wireless range and speed rates are D-Link RELATIVE performance measurements based on the wireless range and speed rates of a standard Wireless G product from D-Link. Maximum throughput based on D-Link Wireless N devices.
2 SharePort support available in router mode only.
3 Power over USB requires direct connection to a PC’s USB port with a minimum output of 500mA.


Gerelateerde Producten

Wireless-N Nano USB Adapter
DWA-131
Meer lezen
Wireless N 150 Pico USB Adapter
DWA-121
Meer lezen
Wireless N USB Adapter
DWA-140
Meer lezen
Xtreme N PCI Express Desktop Adapter
DWA-556
Meer lezen

Technical Specifications

Standards
  • IEEE 802.11b
  • IEEE 802.11g
  • IEEE 802.11n 2.4GHz
  • IEEE 802.3u

Interfaces
  • Mode selection switch (Router / Access Point / Client)
  • 10/100 WAN/LAN Port
  • USB Port for 3G USB adapters4 and SharePort™5
  • WPS button
  • Reset button

Operation Frequencies
  • 2.4 to 2.4835 GHz

Operation Channels
  • FCC: 11
  • ETSI: 13

Operation Modes
  • Router Mode
  • Access Point Mode
  • Wireless Client Mode

Antenna Type
  • 2 Integrated Antennas

Security
  • 64/128-bit WEP
  • Wi-Fi Protected Access (WPA-PSK, WPA2-PSK)®
  • Wi-Fi Protected Setup™ (WPS PIN/PBC)
  • AC Address Filtering
  • Disable SSID Broadcast function

LEDs
  • Power
  • LAN
  • WLAN

Certifications
  • FCC Class B
  • CE
  • C-Tick
  • Wi-Fi®, WPS/Wi-Fi Protected Setup
  • IC

Quality of Service
  • Wi-Fi Multimedia (WMM)

Dimensions
  • 91mm x 65mm x 21.6mm (3.58in x 2.56in x 0.85in)

Weight
  • 64 grams
1 Maximum wireless signal rate derived from IEEE Standard 802.11 specifications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate. Environmental factors will adversely affect wireless signal range. Wireless range and speed rates are D-Link RELATIVE performance measurements based on the wireless range and speed rates of a standard Wireless G product from D-Link. Maximum throughput based on D-Link Wireless N devices.
2 SharePort support available in router mode only.
3 Power over USB requires direct connection to a PC’s USB port with a minimum output of 500mA.
4 Compatible with selected D-Link 3G USB adapters.
5 USB SharePortTM only supported in Router Mode.
