Wireless AC750 Dual Band Gigabit Cloud Router

DIR-818LW

  • Product Status: Phased Out
The DIR-818LW Wireless AC750 Dual-Band Gigabit Cloud Router is an affordable yet powerful wireless networking solution which combines high-speed Wi-Fi with dual-band technology and fast Gigabit ports to deliver a seamless networking experience. Increased range and reliability helps the DIR-818LW reach further into your home, and advanced security features keep your network and data safe from intruders.

Download the datasheet.

List Retailers

Super-Fast Wired and Wireless Connectivity

Enjoy combined wireless speeds of up to 750 Mbps1 with increased range as well as Gigabit wired connectivity, to get the most out of your Internet connection throughout your home.

DIR-818LW

Product Highlights

Super-Fast Wired and Wireless Connectivity

With combined wireless speeds of up to 750 Mbps with increased range as well as Gigabit wired connectivity. Get the most out of your Internet connection throughout your home.

Wireless access to your network

Via two concurrent wireless bands for uninterrupted performance no matter what you are doing.

Access your photos, videos, music, and documents no matter where you are

with the mydlink™ SharePort™ app for your mobile device

The free mydlink™ Lite app and QRS (Quick Router Setup) Mobile app

for your iOS or Android device allows you to set up your network without touching a computer

Wireless AC750 Dual-Band Gigabit Cloud Router

The DIR-818LW Wireless AC750 Dual-Band Gigabit Cloud Router is an affordable yet powerful wireless networking solution which combines high-speed Wi-Fi with dual-band technology and fast Gigabit ports to deliver a seamless networking experience. Increased range and reliability helps the DIR-818LW reach further into your home, and advanced security features keep your network and data safe from intruders. Optional mobile 3G connectivity through DWM-1573 allows you to connect to the Internet, even when fixed line broadband Internet is not available.

Dual Band Wireless for Seamless Performance

The DIR-818LW Wireless AC750 Dual-Band Gigabit Cloud Router gives you lightning-fast Wi-Fi speeds of up to 750 Mbps and increased range. It also uses dual-band wireless, allowing you to operate two concurrent, high-speed Wi-Fi bands for ultimate wireless performance. Surf the web, chat and play online games on the 2.4 GHz band, while simultaneously streaming digital media on the 5 GHz band2. What’s more, each band can operate as a separate Wi-Fi network, giving you the ability to customise your network according to your connectivity needs. You can even configure a guest zone to give visitors Internet access without giving them access to the rest of your network.

Your Own Personal Cloud Storage

Connect a USB storage drive to the DIR-818LW to instantly create a personal, private storage space to access your documents, movies, pictures, and music no matter where you are through the mydlink™ SharePort™ app. Save space on your mobile device by streaming your favourite shows and music, or download specific episodes or songs to your device for offline playback.

Use mydlink™ Lite to Monitor Your Network Anytime

The Wireless AC750 Dual-Band Gigabit Cloud Router is mydlink™-enabled, so you can effortlessly access and view your network no matter where you are. See who is connected to your router, change settings or block someone from using your network connection, all from any Internet connected PC, or an iOS, Android or Windows mobile device. Parents can monitor what sites their children are visiting, and can stay informed and in control on the go.

Easy to Set Up, Easy to Secure

Sharing your Internet connection doesn’t have to be a complicated process.Just open a web browser to access the setup wizard and follow the easy step-by-step instructions to get started. Implement WPA/WPA2 wireless security in minutes with the wireless network setup wizard or use Wi-Fi Protected Setup (WPS), which establishes a secure connection to new devices without the need to enter settings or create passwords. In addition, the built-in firewall protects against malicious attacks from the Internet, and access control features allow you to restrict access to your network, making your connection safe and secure.

1. Maximum wireless signal rate derived from IEEE 802.11n/ac specifications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate. Environmental factors may adversely affect wireless signal range. Wireless range and speed rates are D-Link relative performance measurements based on the wireless range and speed rates of a standard wireless product from D-Link. Maximum throughput based on D-Link 802.11ac devices.
2. A single device can only be connected to either the 2.4 GHz or 5 GHz wireless band.
3 Requires hardware version B running the latest firmware available from
www.dlink.com. DWM-157 3G USB adapter is not included.

Related Products

Wireless AC750 Dual-Band Cloud Router
DIR-816L
Find out more
Wireless AC750 Dual-Band Cloud Router
DIR-810L
Find out more
Wireless AC1200 Dual-Band Gigabit Cloud Router
DIR-850L
Find out more
Wireless AC1200 Dual-Band Gigabit Cloud Router
DIR-860L
Find out more
Wireless AC1750 Dual-Band Gigabit Cloud Router
DIR-868L
Find out more

Technical Specifications

Functions & Features

Features

High-Speed Connectivity

  • Delivers blazing fast wireless connectivity with increased range and reliability
  • Concurrent dual-band wireless for combined2 connections of up to 750 Mbps1
  • Gigabit Ethernet WAN port for speedy Internet access
  • Four Gigabit Ethernet LAN ports give you high-speed wired connectivity
  • Optional 3G connectivity through DWM-157 3G USB adapter3

mydlink™ SharePort™

  • Use the mydlink™ SharePort™ mobile app to access files stored on a connected USB drive over the Internet
  • Stream music and video to your mobile device
  • Upload photos and videos from your camera roll

Mobile Apps

  • mydlink™ Lite helps you access, manage, and view your network remotely across the Internet
  • QRS Mobile sets up your network using a mobile device without the need for a computer

Technical Specifications

General

Device Interfaces

  • IEEE 802.11 a/b/g/n/ac wireless LAN
  • 10/100/1000 Gigabit fast Ethernet WAN port
  • Four 10/100/1000 Gigabit Fast Ethernet LAN ports
  • USB port for optional storage sharing or 3G connectivity3

LEDs

  • Power
  • Internet

Antenna Type

  • Fixed internal

Operating Frequency

  • 2.4 GHz band: 2400 - 2483.5 MHz
  • 5 GHz band: 5150 - 5725 MH

Standards

  • IEEE 802.11ac
  • IEEE 802.11n
  • IEEE 802.11g
  • IEEE 802.11b
  • IEEE 802.11a
  • IEEE 802.3u

Minimum Requirements

  • Internet Explorer 7, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser
  • Ethernet interface or Wi-Fi
  • Cable or DSL modem
  • Subscription with an Internet Service Provider (ISP)

Functionality

Security

  • WPA
  • WPA2
  • 64/128 bits WEP

Firewall

  • Network Address Translation (NAT)
  • Stateful Packet Inspection (SPI)
  • IP/MAC address filtering
  • Denial of Service (DoS)

Advanced Features

  • Web setup wizard
  • QoS (Quality of Service)
  • DMZ (Demilitarised Zone)         Guest zone
  • IPv6 ready

mydlink™ SharePort™ Features

  • Remote Access Mode
  • Local Access Mode
  • SharePort™ Web File Access support (Web browser)
  • Access files from any device connected to the DIR-818LW
  • Accepts USB storage drives up to 250 GB

mydlink™ Lite Features

  • Remote management
  • View current upload/download bandwidth
  • View currently connected clients
  • View Web-browsing history per client
  • Block/unblock client network access
  • Manage wireless network details
  • Accessible through a Web browser or smartphone app

Mobile App Support

  • mydlink™ Lite
  • mydlink™ SharePort™
  • QRS Mobile  Apps support iPhone, iPad, iPod touch, and Android devices

WAN Type Support

  • Static IP
  • Dynamic IP
  • PPPoE
  • PPTP
  • L2TP
  • DS-Lite

IPv6

  • IPv6 Firewall
  • IPv6 Static Routing
  • IPv6 Diagnosis Tool
  • IPv6 DDNS
  • ULA
  • Bonjour
  • Simple Security

Physical

Dimensions

  • 116 x 93 x 145 mm (4.57 x 3.61 x 5.7 inches)

Weight

  • 330 grams (11.64 ounces)

Power

  • Input: 100 to 240 V AC, 50/60 Hz

Temperature

  • Operating: 0 to 40 °C (32 to 104 °F)
  • Storage: -20 to 65 °C (-4 to 149 °F)

Humidity

  • Operating: 10% to 90% non-condensing
  • Storage: 5% to 95% non-condensing

Certifications

  • IC
  • CE
  • FCC
  • CSA
1. Maximum wireless signal rate derived from IEEE 802.11n/ac specifications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate. Environmental factors may adversely affect wireless signal range. Wireless range and speed rates are D-Link relative performance measurements based on the wireless range and speed rates of a standard wireless product from D-Link. Maximum throughput based on D-Link 802.11ac devices.
2 A single device can only be connected to either the 2.4 GHz or 5 GHz wireless band.
3 Requires hardware version B running the latest firmware available from
www.dlink.com. DWM-157 3G USB adapter is not included.
