Dualband PoE 11N Accesspoint

DAP-2590

  • Product Status: Phased Out

The DAP-2590 is a dualband wireless Access Point with PoE, ideal for next generation 802.11n deployments in business-class environments.


Download the datasheet.

List Retailers

Overview

The D-Link DAP-2590 AirPremier N Dual Band PoE Access Point provides businesses with a solution for deploying next generation draft 802.11n Local Area Networks (LANs). Designed for indoor installation, this Access Point enables network administrators to deploy a highly manageable, robust and secure wireless network.

Solid Hardware with PoE support

Enclosed in a sturdy metal chassis, the DAP-2590 passed the strict UL 2043 testing, achieving “Plenum Rating” with its material which has been proven as fire-resistant and would furthermore produce low levels of smoke if the occasion were to arise.

For installations in areas where power outlets are not readily available, the Access Point integrates 802.3af Power over Ethernet (PoE), to ensure flexibility and easy set-up.

Enhanced performance

The DAP-2590 delivers reliable Wireless N performance with no dead spots and rates of up to 300 Mbps in either the 2.4 GHz or 5 GHz wireless band1. Support for the Wi-Fi Multimedia™ (WMM) Quality of Service feature makes it an ideal access point for audio, video, and voice applications. Additionally, this Access Point supports load balancing to optimise high volumes of traffic and redundancy for fail-safe wireless connectivity.

Advanced wireless security

The DAP-2590 provides industrial grade wireless security by supporting both Personal and Enterprise versions of WPA and WPA2 (802.11i) with support for RADIUS server backend. This Access Point also includes MAC Address filtering, Wireless LAN segmentation, Disable SSID Broadcast, rogue AP detection, and Wireless sheduling to further protect your wireless network.

The AirPremier N Dual Band PoE Access Point includes support for up to 8 VLANs for implementing multiple service set identifiers (SSIDs) to further help segment users on the network. With multiple SSIDs, the number of physical APs deployed can be reduced, hence keeping costs to a minimum.

The DAP-2590 also includes a wireless client isolation mechanism to prevent direct client-to-client communication, and a wireless scheduler to shut down the wireless LAN at certain times of the day.

Multiple operation modes

The DAP-2590 can be configured in any one of its multiple operation modes: Access Point, Wireless Distribution System (WDS) with Access Point, WDS/Bridge (No AP Broadcasting) and Wireless Client. With WDS support, network administrators can set up multiple DAP-2590s throughout a facility and configure them to bridge with one another while also providing network access to individual clients.

Advanced Network Management

Network administrators can manage all the DAP-2590's settings via its web-based configuration utility (HTTP), Secure Sockets Layer (SSL), Secure Shell

(SSH), or with Telnet. D-Link's AP Manager or D-View SNMPv3 management module may also be used to configure and manage multiple access points from a single location. In addition to a streamlined management process, network administrators can also verify and conduct regular maintenance checks without wasting resources by sending personnel out to physically test that the device is functioning correctly
1Maximum wireless signal rate based on IEEE standard 802.11g, 802.11a and draft 802.11n specifications. Actual data throughput will vary. Network conditions and environmental factors lower actual data throughput rate.

Utseendet på produkten kan eventuellt avvika i jämförelse med bilden på den här sidan.

Related Products

24-portars 10/100Mbps PoE Layer 2 Smart switch med 4 portar för Gigabit koppar (2 combo SFP) och administration
DES-1228P
Find out more
24-Port xStack Gigabit L2+ Stackable Managed PoE Switch
DGS-3426P
Find out more

Technical Specifications

Hardware

  • Sturdy Plenum rated metal chassis
  • One 10/100/1000 Mbps Gigabit LAN port with built-in 802.3af Power over Ethernet (PoE)
  • Selectable dualband connectivity
  • Three detachable dualband antennae
  • Wall-mounting brackets included

Operation Modes

  • Access Point
  • Wireless Distribution System (WDS), for either Point-to-Point or Point-to-Multipoint bridge
  • WDS with AP
  • Wireless client

High Performance Connectivity

  • IEEE 802.11n
  • Up to 300 Mbps wireless data transfer rates*

* Maximum wireless signal rate based on IEEE standard 802.11g, 802.11a and 802.11n specifications. Actual data throughput will vary. Network conditions and environmental factors may lower actual data throughput rate.

Security

  • WPA™ Personal/WPA™ Enterprise
  • WPA2™ Personal/WPA2™ Enterprise
  • WPA2-PSK/AES over WDS
  • MAC Address Filtering

Management

  • AP Manager II
  • Web Browser (HTTP/HTTPS)
  • Telnet
  • SSH
  • SNMP v1, v2c, v3
  • D-View 5.1 and 6.0

FAQ

  • What is the advantage of using WPA over WEP security? Read Answer
Version Date Type File Size
Datasheet (English) - PDF 4.47mb Download
Version Description Date Type File Size
Manual (English)

Manual (English)

- PDF 3.69mb Download
AP Manager II - User AP Manager II - User Manual (English) - PDF 5.96mb Download
Version Description Date Type File Size
Quick Installation Guide (Multilingual) - PDF 1.91mb Download
This D-Link product includes software code developed by third parties, including software code subject to the GNU General Public License (“GPL”) or GNU Lesser General Public License (“LGPL”). As applicable, the terms of the GPL and LGPL, and information on obtaining access to the GPL code and LGPL code used in this product, are available to you at:

http://tsd.dlink.com.tw/GPL.asp

The GPL code and LGPL code used in this product is distributed WITHOUT ANY WARRANTY and is subject to the copyrights of one or more authors. For details, see the GPL code and the LGPL code for this product and the terms of the GPL and LGPL.
Version Description Date
Firmware 1.25rc056

Firmware

2013-05-15 Download
Firmware 1.20 rc039 Firmware 2012-07-26 Download
Version Description Date
MIB file 1.15 rc012 MIB file 2011-08-15 Download
AP Manager II v 1.13 1.13 r38

AP Manager II v 1.13

Release notes enclosed.

2011-01-06 Download
Version Description Date
CE Declaration - ver A2 CE Declaration - ver A2 (English, French) 2009-08-21 Download
