Xtreme N Duo Wireless N Access Point

DAP-1522

  • Product Status: Phased Out

Create a new Wi-Fi network or wirelessly connect two networks together with the D-Link Xtreme N Duo Wireless Bridge/Access Point (DAP-1522). Optimize your new or expanded network to stream HD media, play multiplayer games, or make Internet phone calls (VoIP).

  • 4-Port switch adds wireless connectivity to Ethernet-enabled devices in your entertainment center
  • Dual band technology helps avoid interference and ensures smooth video streaming and online gaming
  • Wi-Fi Protected Setup Push Button for simple installation
  • WPA and WPA2 encryption provides high-level security for your network
  • Backward compatible with Wireless G devices

Download the datasheet.

List Retailers
Dual Band Wireless Networking
The D-Link® Xtreme N™ Duo Wireless Bridge/Access Point is designed for users looking to create a wireless network or to connect multiple wired devices to an existing wireless network. Xtreme N Duo is the latest addition to the award-winning Xtreme N product family. Duo means the DAP-1522 works with next generation dual band (2.4GHz or 5GHz)* 802.11n wireless devices as well as legacy 802.11g products.

Connect Multiple Devices

The wireless bridge feature of the DAP-1522 allows you to easily connect up to 4 Ethernet-enabled devices in your entertainment center to your wireless network. Connect devices such as Game Consoles, Digital Video Recorders (DVR), and Digital Media Adapters (DMA) to the built-in 4-Port Gigabit Switch.

Create a Wireless Network
Create a new wireless network using the Access Point feature by connecting the DAP-1522 to an existing wired network. Use your new wireless network to stream high-definition (HD) video, play multiplayer games, or make phone calls (VoIP) using the built-in dual band technology.

5GHz Technology
The DAP-1522 has selectable 2.4GHz or 5GHz bands. 5GHz is ideal for wirelessly streaming multiple HD videos across your network. It helps avoid interference by providing a clearer wireless band for HD signals than existing 2.4GHz products.

Delivering superior wireless performance, clarity, and coverage, the Xtreme N Duo Wireless Bridge/Access Point (DAP-1522) is the ideal addition to your wireless network in the home.

Wireless Bridge Mode
Use the xtreme N™ duo wireless bridge / access point (DAP-1522) to connect up to 4 Ethernet-enabled devices such as Game Consoles, Digital Video Recorders (DVR), and Digital Media Adapters (DMA) to your wireless network.

Access Point Mode
Connect the DAP-1522 to an existing wired network and easily enable wireless connectivity in your home. Use your new wireless network to stream HD multimedia content, play multiplayer games, or make Internet phone calls (VoIP).

* Due to government regulations the 5.25~5.35GHz and 5.47~5.725GHz wireless bands are removed.

Product Awards

Hardware Silver Award

Related Products

Wireless N Dual Band Router
DIR-815
Find out more
Xtreme N Dual Band Gigabit Router
DIR-825
Find out more
Dualband HD Media Router
DIR-857
Find out more

Technical Specifications

Hardware

  • Four 10/100/1000 Mbps Gigabit LAN ports
  • Internal antenna

Wireless

  • Dualband technology, up to 300 Mbps in each frequency band
  • IEEE 802.11n (draft 2.0) Wireless LAN specification, Wi-Fi certified
  • Selectable 2.4GHz and 5GHz Wireless N operation
  • Backward compatible with 802.11a/g wireless networks
  • Simple wireless encryption set up at the touch of a button (Wi-Fi Protected Setup)

Security

  • 64/128-bit WEP
  • WPA™- PSK, WPA2 ™- PSK (Wi-Fi Protected Access)
  • WPS (Wi-Fi Protected Setup)

Management

  • Three operation modes; AP, Bridge and Auto
  • Web-based management

Warranty

  • 2-year warranty

FAQ

  • What is the advantage of using WPA over WEP security? Read Answer
How to connect to wireless in Windows 8
How to connect to wireless in Windows 7
How to connect to wireless using an iPhone

Downloads can vary across product revisions. Please select the correct hardware revision.
