Description
With its compact, all-in one design, the DCS-900W is a great remote monitoring solution for your home.
The
D-Link Securicam NetworkTM DCS-900W Internet Camera with its
compact, all-in-one design, is a great remote monitoring solution for your home. The
DCS-900W Internet Camera connects quickly and easily to your existing Fast Ethernet
network or 802.11b wireless network and a setup wizard will guide you through the
setup process to get you up and running in a matter of minutes.
The DCS-900W
Internet Camera features a built-in Web server, which means that it can stream video
images directly to the Internet. Video images captured by the DCS-900W can be viewed
remotely by typing the IP address of the DCS-900W into a Web browser. With its
easy-to-use Web-based interface, the DCS-900W Internet Camera can be managed and
configured from anywhere in the world.
By signing up with one of the many free
Dynamic DNS services available on the web, you can assign an easy-to-remember name and
domain (e.g. www.mycamera.myddns.com). This allows you to remotely access your camera
without having to remember the IP address, even if it has been changed by your
Internet Service Provider.
The included Windows-based IPView Lite software
provides even more features, allowing you to archive streaming video straight to your
hard drive, monitor up to 4 cameras on a single screen, rotate camera views, enable
motion detection, and update the firmware on your DCS-900W Internet Camera.
Features
- Web-based Remote Access Using Any Java Enabled Web Browser
- 802.11b Wireless or 10/100Mbps Fast Ethernet Connection
- Scheduled, Motion triggered or Manual recording options
Specifications
| General | - Built-in Web Server
- 802.11b Wireless or 10/100Mbps Fast Ethernet Network Access
| | Web Access Requirements | - Any Java-Enabled or ActiveX compatible Web Browser,. i.e. current versions of Microsoft Internet Explorer or Netscape Navigator.
| IPView Lite Management Software Requirements | - Microsoft Windows XP, 2000, Me, 98SE
| | Video | - 1/3” CMOS Digital VGA Sensor
- 24-bit RGB color
- Resolution: 640x480, 320x240
- 5 Level User Selectable JPEG Compression Rate
- Frame Rate*: 1, 5, 7, 15, 20 or Auto
| | Exposure | - Brightness Control: Slide bar
- Contrast Control: Slide bar
- Hue Control: Slide bar
- Shutter: 1/60 ~ 1/15000 sec
- Minimum Illumination: 2.5lux@f1.4, 3000K color
| | Lens | - Fixed Lens
- Focus: 20cm ~ infinity
- Manual Focus
- Aperture: F 1.8
- Focal Length: 6.0 mm
| | Users | | | Firmware Updates | - IPView Lite Management Software
| | Protocol Support | - HTTP, TCP/IP, UDP, RARP, PING, ARP, DNS, DDNS, DHCP, BOOTP, PPPoE
| | Network Interface | - 802.3/802.3u NWAY Autosensing 10/100Mbps (RJ-45 Jack)
- 802.11b Wireless
| IPView Lite Management Software | - Remotely manage and control up to 4 DCS-900W Internet Cameras
- Works with Microsoft Windows XP, 2000, Me, 98SE
- View 1 or 4 Cameras on one screen
- Supports all management functions provided in Web interface
- Record streaming video to hard drive in AVI format
- Scheduled, Motion triggered or Manual recording options
| | Hardware | - Power Supply: DC 5V/2.5A
- Power Requirements: 4.5Watt (900mA x 5V)
- Indoor Use Only. Outdoor Use Requires Protective Housing.
- Operating Temperature: 5° ~ 40°C
- Storage Temperature: -25° ~ 50°C
- Humidity: 5% ~ 95% (non-condensing)
- Size: 2.5” (L) x 2.5" (W) x 2.75" (H)
- Weight : 0.6lbs
| | LED Indicator | - Power & Link
- Selectable LED Control: Normal, Off, Dummy
| | EMI & Safety | | | Accessories Included | - CAT5 Fast Ethernet Cable
- AC Power Adapter
- One 802.11b Wireless Antenna
- Swivel Stand
- CD with IPView Lite Software
- Manual
- Quick Install Guide
| | Warranty | 1 Year |
|
*- Note: File size and network bandwidth depend on actual image content, lightness/darkness of content, frame rate, compression level, resolution. Higher compression and low frame rate result in lower bandwidth requirements, while low compression and high frame rates result in higher network bandwidth and higher image quality.
