Wireless PoE Access Point

DWL-3200AP

  • Status produktu: Wycofany ze sprzedaży

The DWL-3200AP Wireless PoE Access Point is a powerful and reliable wireless access point for business-class enterprise environments. Designed for indoor installation, this access point provides secure options for network administrators to deploy a highly manageable and extremely robust wireless network. This access point supports Power over Ethernet (PoE) and provides two high-gain antennas for optimal wireless coverage.


Pobierz kartę produktu.

Lista sklepów

For Business-Class Environments

The DWL-3200AP Wireless PoE Access Point is a powerful and reliable wireless access point for business-class enterprise environments. Designed for indoor installation, this access point provides secure options for network administrators to deploy a highly manageable and extremely robust wireless network. This access point supports Power over Ethernet (PoE) and provides two high-gain antennas for optimal wireless coverage.

PoE Support

Enclosed in a plenum metal chassis, the DWL-3200AP adheres to strict fire codes and ensures complete safety. For advanced installations, this high- speed access point has an integrated 802.3af Power over Ethernet (PoE) support to allow installation in areas where power outlets are not readily available.

Up to 108Mbps Wireless Speed

The DWL-3200AP delivers extremely reliable wireless performance with standard 802.11g wireless throughput rates of up to 54Mbps. It has the added capability of reaching maximum wireless signal rates of up to 108Mbps (Turbo mode) powered by D-Link 108G technology. At the same time, the DWL- 3200AP remains fully compatible with the IEEE 802.11b and 802.11g standards.

Advanced Wireless Security

Since wireless security remains a strong concern among businesses, the DWL-3200AP provides the latest wireless security technologies by supporting both WPA Enterprise and 802.1x to ensure complete network protection. In addition, the DWL-3200AP currently comes 802.11i-ready to fully support industrial grade wireless security.

Advanced Network Management

Network administrators can manage all the DWL-3200AP's settings via its web-based configuration utility or with Telnet. For advanced network management, the administrators can use D-Link's AP Manager or D-View SNMP management module to configure and manage multiple access points from a single location. In addition to a streamlined management process, network administrators can also verify and conduct regular maintenance checks without wasting resources by sending personnel out to physically verify proper operation.

WDS (Wireless Distribution System) Support

To maximize total return on investment, the DWL-3200AP can be configured to operate as an access point (AP mode), a point-to-point bridge or a point-to-multipoint bridge (WDS mode). In the WDS mode, the DWL-3200AP communicates only with wireless bridges, without allowing for wireless clients or stations to access them.


Actual product appearance may differ from the image displayed on this page

Sugerowane urządzenia

Wireless N PoE Access Point
DAP-2360
Dowiedz się więcej

Technical Specifications

Standards
  • IEEE 802.11b
  • IEEE 802.11g
  • IEEE 802.3
  • IEEE 802.3af
  • IEEE 802.3u

Network Management
  • Web Browser Interface
  • HTTP
  • Secure HTTP (HTTPS)
  • AP Manager II
  • SNMPv3 Support D-View Module
  • Private MIB
  • Command Line Interface
  • Telnet
  • Secure (SSH) Telnet

MAC Address Table
  • 16K
  • Wireless Signal Rates* With Automatic Fallback For 802.11g:
  • 108, 54, 48, 36, 24, 18, 12, 9 and 6Mbps for 802.11b:
  • 11, 5.5, 2, and 1Mbps

Security
  • WPA – Personal
  • WPA – Enterprise
  • WPA2 – Personal
  • WPA2 – Enterprise
  • 64/128/152-bit WEP
  • SSID Broadcast Disable
  • Rogue AP Detection
  • MAC Address Access Control List
  • Isolated Security Setting for Each SSID

Wireless Frequency Range
  • 2.4GHz to 2.4835GHz
  • Wireless Signal Range* 802.11g (Full Power with 5dBi Gain Diversity Dualband Dipole Antenna)
  • Indoors: 98ft (30m) @ 54Mbps
  • 112ft (34m) @ 48Mbps
  • 128ft (39m) @ 36Mbps
  • 154ft (47m) @ 24Mbps
  • 184ft (56m) @ 18Mbps
  • 217ft (66m) @ 12Mbps
  • 259ft (79m) @ 9Mbps
  • 325ft (99m) @ 6Mbps
  • Outdoors: 367ft (112m) @ 54Mbps
  • 820ft (250m) @ 18Mbps
  • 1640ft (500m) @ 6Mbps

Operating Voltage
  • 48VDC +/- 10% for PoE
  • Radio and Modulation Type* For 802.11b:
  • DSSS : DBPSK @ 1Mbps
  • DQPSK @ 2Mbps
  • CCK @ 5.5 and 11Mbps
  • For 802.11g:
  • OFDM: BPSK @ 6 and 9Mbps
  • QPSK @ 12 and 18Mbps
  • 16QAM @ 24 and 36Mbps
  • 64QAM @ 48, and 54Mbps
  • DSSS: DBPSK @ 1Mbps
  • DQPSK @ 2Mbps
  • CCK @ 5.5 and 11Mbps

Operating Modes
  • Access Point
  • WDS with AP
  • WDS/Bridge (No AP Broadcasting)

Antenna
  • Dual 5dBi Gain Detachable Diversity Dipole Antennas with Reverse SMA Connectors

Maximum Transmit Output Power
  • For 802.11b: 21dBm
  • For 802.11g: 21dBm

Maximum EIRP (Effective Isotropic Radiated Power)
  • Total Output Power (Output Power with 5dBi Antenna)
  • For 802.11b: 26dBm
  • For 802.11g: 26dBm

LEDs
  • Power
  • LAN
  • 802.11b/g

Maximum Power Consumption
  • 6.42 Watts (130mA)

Temperature
  • Operating: 32 ºF to 104ºF (0ºC to 40ºC)
  • Storing: -4ºF to 149ºF (-20ºC to 65ºC)

Humidity
  • Operating: 10%~90% (Non-Condensing)
  • Storing: 5%~95% (Non-Condensing)

Certifications
  • FCC Class B
  • Wi-Fi®
  • CE
  • C-Tick
  • UL

Dimensions (W x D x H)
  • 6.48” x 7.27” x 1.25” (164.59mm x184.66mm x 31.75mm)

Weight (lbs)
  • 1.33lbs (603.28g)

Warranty
  • Limited Lifetime
