Wireless VPN Security Router

DSR-150N

  • Status produktu: Wycofany ze sprzedaży
The DSR-150N Wireless VPN Security Router is an all-in-one networking solution for small businesses as well as branch offices. The integrated high-speed IEEE 802.11n wireless technology offers comparable performance to traditional wired networks, but with fewer limitations. The DSR-150 provides optimal network security via features such as Virtual Private Network (VPN) tunnels, IP Security (IPSec), Point-to-Point Tunneling Protocol (PPTP), Layer 2 Tunneling Protocol (L2TP), Generic Routing Encapsulation (GRE)1, and Secure Sockets Layer (SSL). It also allows you and colleagues to stay connected to the office with clientless remote access anywhere and anytime using SSL VPN tunnels.

Pobierz kartę produktu.

Lista sklepów

2

Years Warranty

3G

Network Support

300 Mbps

Capability

MIMO

Technology

Integrated Wireless Connectivity


The DSR-150N Wireless VPN Security Router is an all-in-one networking solution. Integrated high-speed IEEE 802.11n wireless technology offers comparable performance to traditional wired networks, but with fewer limitations. Support for separate Virtual LANs (VLANs) means the network can be partitioned, for instance to enable visitors to connect to the Internet without giving them access to the full corporate network.


Flexible Deployment Options


With 3G mobile Internet connectivity support via an optional 3G USB dongle3. This 3G network capability offers the ability to stay connected when wired Internet is not available or as a backup if the wired Internet connection fails.

Security


This affordable, high performance router also enables businesses to secure their network whether in the office, at home or out on the road. You and your colleagues can stay connected to the office anywhere, anytime.

Complete VPN features, as well as IPSec Hub and Spoke technology, ensures secure communication between mobile employees and offices.

Features

VPN

A fully featured virtual private network (VPN) provides your mobile workers and branch offices with a secure link to your network.

SSL

A Secure Sockets Layer (SSL) VPN tunnel provides remote access to a central corporate network

GRE

5 Generic Routing Encapsulation (GRE) tunnels, empowering your mobile users by providing remote access to a central corporate database

IPSec

Site-to-site VPN tunnels use IP Security (IPSec) Protocol

PPTP

Point-to-Point Tunneling Protocol (PPTP)

L2TP

Layer 2 Tunneling Protocol (L2TP) to facilitate branch office connectivity through encrypted virtual links

Efficient Green Technology


D-Link Green Wi-Fi and D-Link Green Ethernet features save power and help cut energy usage costs. The D-Link Green WLAN Scheduler shuts down your wireless network automatically according to a schedule you define, allowing you to turn it off during off-peak hours, saving energy and keeping your network secure. The D-Link Green Ethernet feature can detect if a link is down on a port, and automatically puts that port into a sleep mode that drastically reduces the amount of power used. In addition, compliance with RoHS (Restriction of Hazardous Substances) and WEEE (Waste Electrical and Electronic Equipment) directives make D-Link Green-certified devices an environmentally responsible choice.


1 Available through future firmware upgrade.
2 Maximum wireless signal rate derived from IEEE Standard 802.11. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate. Environmental factors may adversely affect wireless signal range.
3 The following 3G dongles are supported: DWM-152 A1/A2/A3, DWM-156 A1/A2/A3/A5*/A6*, DWM-157*, Huawei E1550, E173, and EC306.* The dongles marked with * will be supported through firmware upgrades.

Sugerowane urządzenia

Wireless N Dual Band Unified Service Router
DSR-1000N
Dowiedz się więcej
Wireless N Unified Service Router
DSR-250N
Dowiedz się więcej
Wireless N Unified Services Router
DSR-500N
Dowiedz się więcej

Technical Specifications

Functions & Features

Features

VPN
  • Protocols
    • IPSec
    • PPTP/L2TP
    • GRE
    • SSL
  • VPN Throughput (3DES)6
    • 40 Mbps
  • VPN Tunnels
    • Up to 26 tunnels
  • DES, 3DES, AES
Firewall3
  • Firewall Policies
    • 200
  • Firewall Throughput
    • 95 Mbps
Enhanced Network Services
  • IPv6
  • IEEE 802.1q VLAN
  • Multiple SSIDs
  • Port Monitoring/Bandwidth Control
  • srTCM, trTCM, & policing
Wireless Access and Security
  • IEEE 802.11 b/g/n (2.4 GHz)
  • IEEE 802.1x RADIUS Authentication with EAP-TLS, EAP-TLLS, EAP-PEAP
  • WPS, WEP, WPA-PSK, WPA-EAP, WPA2-PSK, WPA2-EAP
Technical Specifications General
  • Ethernet Interface
    • 1 x 10/100 Mbps WAN Port
    • 8 x 10/100 Mbps LAN Ports
  • Wireless Interface
    • 802.11b/g/n (Single Band)
    • 2 Internal 2dBi Omni-Directional Antennas
  • USB 2.0 Ports
    • 1
  • Console Port
    • RJ-45
Performance6
  • Firewall Throughput5
    • 95 Mbps
  • VPN Throughput (3DES)7
    • 40 Mbps
  • Concurrent Sessions
    • 20,000
  • New Sessions (per second)
    • 200
  • Firewall Policies
    • 200
Internet Connection Type
  • Static/ Dynamic IP
  • PPPoE/ L2TP/ PPTP
  • Multiple PPPoe
Firewall System
  • Static Route
  • Dynamic DNS
  • Inter-VLAN Route
  • NAT, PAT
  • Web Content Filtering
    • Static URL
    • Keywords
Networking
  • DHCP Server/ Client
  • DHCP Relay
  • IEEE802.1q VLAN
  • VLAN (Port-Based)
  • IP Multicast
    • IGMP Proxy
  • IPv62
  • 3G Redundancy
Wireless2
  • Multiple Service Set Identifier (SSID)
  • Service Set Identifier (SSID) to VLAN Mapping
  • Standards
    • 802.11b/g/n
  • Wireless Security
    • Wired Equivalent Privacy (WEP)
    • Wi-Fi Protect Setup (WPS)
    • Wi-Fi Protected Access – Personal (WPA-PSK)
    • Wi-Fi Protected Access – Enterprise (WPA-EAP)
    • Wi-Fi Protected Access version 2 – Personal (WPA-PSK)
    • Wi-Fi Protected Access version 2 – Enterprise (WPA-EAP)
Virtual Private Network (VPN)
  • VPN Tunnels
    • 26
  • IPSec Tunnels
    • 10
  • SSL VPN Tunnels
    • 1
  • PPTP/L2TP Clients
    • 10
  • GRE1
    • 5
  • Encryption Methods
    • DES
    • 3DES
    • AES
    • Twofish
    • Blowfish
    • CAST-128
    • NULL
  • SSL Encryption Methods
    • RC4-128
    • 3DES
    • AES
  • IPSec/PPTP/L2TP Server
  • IPSec NAT Traversal
  • Dead Peer Detection
  • IP Encapsulating Security Payload (ESP)
  • IP Authentication Header (AH)
  • VPN Tunnel Keep Alive
  • Hub and Spoke
Bandwidth Management
  • Maximum Bandwidth Control
  • Priority Bandwidth Control
    • Port-based QoS
    • 3 Classes
System Management
  • Web-based User Interface
    • HTTP
    • HTTPS
  • Command Line
  • SNMP
    • v1, v2c, v3
Physical & Environment
  • Power Supply
    • External Power Supply Unit
    • DC 12 V/1.5 A
  • Max. Power Consumption
    • 10.5 W
  • Dimensions (L x W x H)
    • 208 x 118 x 35 mm (8.19 x 4.65 x 1.38 inches)
  • Operation Temperature
    • 0 to 40 °C (32 to 104 °F)
  • Storage Temperature
    • -20 to 70 °C (-4 to 158 °F)
  • Operation Humidity
    • 5% to 95% non-condensing
  • EMI/EMC
    • FCC Class B, CE Class B, C-Tick, IC
  • Safety
    • cUL, LVD (EN60950-1)
  • 3rd Party Certification
    • IPv6 Ready, Wi-Fi, ICSA-Certified Firewall, VPNC AES Interop, VPNC Basic Interop
  • MTBF
    • 240,000 hours
