Outdoor Full HD Vandal-Resistant Mini Fixed Smoked Dome Network Camera

DCS-6210BS

  • Status produktu: wycofany ze sprzedaży

This high resolution outdoor fixed dome camera is super tough, vandal resistant, and weatherproof. Equipped with a high resolution megapixel sensor to provide Full HD images to 1080p and high quality detailed video and also comes with SD card slot for event recording and storage. The tough, rugged, IP-68 housing lets this high resolution dome camera withstand the harshest environments.


Pobierz kartę produktu.

Lista sklepów

The DCS-6210BS Full HD Vandal-Resistant Mini Fixed Smoked Dome Network Camera  is an industry rated vandal proof and weatherproof camera suited for deployment in a wide range of difficult locations. Furthermore, the smoked dome offers an additional degree of surveillance by hiding the direction where the lens is actually pointing without affecting picture quality.

Built for Tough Environments

The DCS-6210BS has a toughened metal, industry-certified IK-10 (vandal-proof) and IP-68 (weather-proof) housing, specially designed for use in harsh environments. Specifically built to withstand sudden high impact and adverse weather conditions.

Flexible Installation

The DCS-6210BS carries a Power over Ethernet (PoE) port which allows you to connect the camera to your network and power it through a single cable. This both, expands and simplifies your options by doing away with the need for a nearby power outlet, making installation on ceilings much easier.

Surveillance in Full High Definition

The DCS-6210BS is built with a megapixel image sensor to give you high-quality snapshots and video with resolutions up to 1080P HD. This gives you sharp, high-resolution pictures and videos with rich detail.
Get a closer look with ePTZ, which lets you zoom in, zoom out, and pan across your camera’s video so you can survey a large area easily.

A Complete, Expandable Surveillance Solution

The DCS-6210BS is a self-sufficient surveillance solution, capable of recording snapshots and video to a MicroSD card without requiring a PC or network storage device.

If you want to expand your surveillance options, D-ViewCam™ management software is also included, giving you the ability to manage up to 32 cameras with a robust set of features, including multi-camera views and automated e-mail alerts to keep you informed of suspicious or unusual activities.

Built for Versatility

The DCS-6210BS comes with a wealth of features that enhance its surveillance capabilities, making it ideal for any situation. It’s 3 axis lens mounting allows you to position it perfectly, while its motion detection capabilities allow it to automatically record video and send you a notification when motion is detected.

Backlight Compensation

Allows every detail to be captured accurately even if one portion is bright while other portions are dark to deliver high quality images

3-Axis Mechanism

DCS-6210BS supports 3 axis mechanism for horizontal, vertical and rotate adjustment to achieve the view you want.

Sugerowane urządzenia

Full HD WDR Varifocal Day & Night Outdoor Smoked Dome Network Camera
DCS-6314BS
Dowiedz się więcej
Outdoor 20X Full HD WDR Smoked Speed Smoked Dome Network Camera
DCS-6915BS
Dowiedz się więcej
Outdoor Full HD Vandal-Resistant Mini Fixed Dome Network Camera
DCS-6210
Dowiedz się więcej
JustConnect Multifunctional Network Video Recorder
DNR-2060-08P
Dowiedz się więcej
2-Bay Professional Network Video Recorder
DNR-326
Dowiedz się więcej

Technical Specifications

Key Features

Camera

  • 1/2.7” 2 megapixel progressive CMOS sensor
  • Megapixel Fixed lens: 3.6 mm F1.8
  • Built-in microphone
  • IP-68 weather proof certified
  • IK-10 vandal proof certified
  • Smoked dome cover
  • ONVIF compliant

Connections

  • 10/100 Fast Ethernet port with PoE
  • Micro SD/SDHC Card slot for onboard storage

Image & Video

  • Real-time H.264/ MPEG-4/ MJPEG
  • Max. resolution 1920x1080 at 15 fps
  • Simultaneous streams
  • ePTZ for virtual PTZ operation
  • Motion detection
  • Privacy mask
  • Multicast video/audio stream
  • Samba client for NAS
  • Multiple access lists

Camera

Camera Hardware Profile

  • 1/2.7” 2 Megapixel progressive CMOS sensor
  • Fixed Lens, focal length 3.6 mm, aperture F1.8
  • 10x digital zoom
  • Angle of view:
    • (H) 88°
    • (V) 50.4°
    • (D) 101°

Camera Housing

  • IP-68 weather-proof compliant
  • IK-10 vandal-proof compliant
  • Smoked dome cover

Image Features

  • Configurable image size, quality, frame rate, and bit rate
  • Time stamp and text overlays
  • Configurable motion detection windows
  • Configurable privacy mask zones
  • Configurable white balance, brightness, saturation, contrast, sharpness and BLC

Video Compression

  • Simultaneous H.264/MPEG-4/MJPEG format compression
  • H.264/MPEG-4 multicast streaming
  • JPEG for still images

Video Resolution

  • 16:9 - 1920 x 1080 (up to 15 fps), 1280 x 720, 800 x 450, 640 x 360, 480 x 270, 320 x 176, 176 x 144 up to 30 fps recording
  • 4:3 - 1440 x 1080 (up to 15 fps), 1280 x 960, 1024 x 768, 800 x 600, 640 x 480, 320 x 240, 176 x 144 up to 30 fps recording

Audio Support

  • G.726
  • G.711

External Device Interfaces

  • 10/100 BASE-TX Fast Ethernet port
  • Supports 802.3af PoE
  • MicroSD/SDHC card slot
  • 12 VDC, 100 mA Output

Network

Network Protocols

  • IPv6
  • IPv4
  • TCP/IP
  • UDP
  • ICMP
  • DHCP client
  • NTP client (D-Link)
  • DNS client
  • DDNS client (D-Link)
  • SMTP client
  • FTP client
  • HTTP / HTTPS
  • Samba client
  • PPPoE
  • UPnP port forwarding
  • RTP / RTSP/ RTCP
  • IP filtering
  • QoS
  • CoS
  • Multicast
  • IGMP
  • ONVIF compliant

Security

  • Administrator and user group protection
  • Password authentication
  • HTTP and RTSP digest encryption

System Management

System Requirements for Web Interface

  • Browser: Internet Explorer, Firefox, Chrome, Safari

Event Management

  • Motion detection
  • Event notification and uploading of snapshots/video clips via e-mail or FTP
  • Supports multiple SMTP and FTP servers
  • Multiple event notifications
  • Multiple recording methods for easy backup

Remote Management

  • Take snapshots/video clips and save to local hard drive or NAS via web browser
  • Configuration interface accessible via web browser

D-ViewCam™ System Requirements

  • Operating System: Microsoft Windows 7/Vista/XP
  • Web Browser: Internet Explorer 7 or higher
  • Protocol: Standard TCP/IP

D-ViewCam™ Software Functions

  • Remote management/control of up to 32 cameras
  • Viewing of up to 32 cameras on one screen
  • Scheduled motion triggered, or manual recording options
  • Supports all management functions in web interface

Physical

Weight

  • 412.2 g ± 5%

Dimensions

  • 115.52 x 106.75 x 51.59 mm

Power Consumption

  • 7.8 watts ± 5%

Temperature

  • Operating: -25 to 50 °C (-22 to 122 °F)
  • Storage: -20 to 70 °C (-4 to 158 °F)

Humidity

  • Operating: 20% to 80% non-condensing
  • Storage: 5% to 95% non-condensing

Certifications

  • CE
  • CE LVD
  • FCC
  • C-Tick
