Dualband HD Media Router

DIR-857

  • Product Status: Phased Out

Supercharge your wireless home network with the Dual-band HD Media Router (DIR-857) optimized for high quality HD video and blazing speed online gaming. HD Fuel technology lets you watch Netflix and LOVEFiLM, play online with your Wii or XBox 360 or make Skype calls- all without the worry of skipping or latency experienced with standard routers. With the DIR-857, enjoy the highest dual band performance available, streaming HD movies and surfing the web at the same time without skipping or lag.


Download the datasheet.

List Retailers
Dual Band = Unlimited Connectivity for all your Devices

Dual-band wireless means you get two N450 frequency (2.4HGHz and 5GHz) channels of bandwidth operating simultaneously, with each frequency transferring up to 450 Mbps. Power your iPad®, iPhones®, security cameras, multiple laptops and all your favorite wireless devices on one 450 Mbps channel, and run your high definition audio and video digital entertainment center and gaming systems on the other.

Gigabit Ethernet Ports =Unlimited Home Networking
The HD Media Router 3000 also offers Gigabit Ethernet ports to ensure that up to four (4) of your favorite Ethernet-enabled devices get the most out of their wired connection. HDTVs, the Boxee Box by D-Link, xBox 360, Blu-Ray Players – connect them all, all at once. The HD Media Router 3000 organizes and manages your traffic flow and gets the most out of your broadband connection for seamless 1080p HD video streams and online gaming without annoying glitches or lags.

Connect to Absolutely Anything – All-at-Once
HDTVs, the Boxee Box by D-Link, Blu-Ray Players, Playstation 3 – the HD Media Router 3000 has been engineered to not only deliver seamless connectivity to your favorite Ethernet-enabled devices, but ANY device. Connect printers, NAS servers - even security cameras - SharePort Plus USB 3.0 lets you connect to and stream from any USB device. We’ve included an SD card slot for uploading HD media files like video and photos and with DLNA standard, the HD Media Router can connect to any device, automatically.

Advanced Home Networking Simple Setup
High-performance entertainment devices. Wireless signals anywhere in your home. Multiple laptops. Network storage systems. iPads, iPhones – It used to be that designing a home network capable of handling so many devices required some serious hardware and some seriously messy installation. Not with Amplifi - the HD Media Router 3000 has not only been engineered with the power to handle all of your digital demands, but with the smarts to put it at the tip of your fingers. HD Media Routers offer Wireless G backwards compatibility and Wi-PnP technology for simple wireless connections through a USB drive. With DLNA, the HD Media Router 3000 not only connects to any Ethernet-equipped device, but virtually any device, automatically. With push-button connectivity and 128-bit security encryption standard, a secure home network is as simple as plug and play.

128-bit Security Encryption
The HD Media Router 3000 protects your network with 128-bit AES data security encryption – the same technology used in E-commerce or online banking. Create your own network name and password or put it at the tip of your fingers with ‘Push Button Security’ standard on every Amplifi device. With hassle-free plug and play installation, and advanced Wi-Fi protected setup, the HD Media Router 3000 is not only one of the fastest routers available, its also one of the safest.

Get Ready for the Future - IPv6 Equipped
With the growing number of Internet-enabled applications requiring IP addresses, the supply of IP addresses under the current Internet Protocol version 4 (IPv4) system has already been exhausted. The IPv6 protocol solves this network addressing exhaustion by creating more IP addresses, but migration from IPv4 to IPv6 is not necessarily automatic. No worries - This D-Link product is IPv6 Certified and ready for the future. IPv6 allows for intelligent self-detect and router setup.

1 Maximum wireless signal rate derived from IEEE Standard 802.11 specifications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate. Environmental factors will adversely affect wireless signal range. Wireless range and speed rates are D-Link RELATIVE performance measurements based on the wireless range and speed rates of a standard Wireless G product from D-Link. Maximum throughput based on D-Link Wireless N devices.
2 24/7 Basic Installation Support is available only in the USA for the first 30 days from date of original purchase.
3 1-Year Limited Warranty available only in the USA and Canada.

Product Awards

Top prize in the Networking and Storage category for D-Link Amplifi™ HD Media Router 3000 (DIR-857)
”We lugged our laptops and cameras for miles, across the show floors, through launch parties, and to closed-door meetings. We found the gadgets of tomorrow – and after sorting through them all – chose D-Link’s HD Media Router 3000 (DIR-857) with SharePort™ technology for our hard-fought ‘Best of CES’ award.”
2012 CES Innovations Design and Engineering Honouree for DIR-857 Amplifi HD Media Router 3000
Products entered in this prestigious program are judged by a preeminent panel of independent industrial designers, engineers, and members of the media to honour outstanding design and engineering in cutting edge consumer electronics products across 32 product categories.

Related Products

Xtreme N Duo Wireless N Access Point
DAP-1522
Find out more
Xtreme N Dual Band USB Adapter
DWA-160
Find out more
Wireless N 300 Dual Band PCI Express Desktop Adapter
DWA-566
Find out more

Technical Specifications

Standards
  • IEEE 802.11n
  • IEEE 802.11g
  • IEEE 802.11a
  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 802.3ab

Physical Interface
  • 4 Gigabit Ethernet Ports
  • 1 WAN Port
  • USB 3.0
  • 1 SD Card Slot
  • 1 WPS Push Button

Antenna Type
  • Internal Antennas

Security
  • WPA-Personal
  • WPA2-Personal

Advanced Firewall Features
  • Network Address Translation (NAT)
  • Stateful Packet Inspection (SPI)
  • VPN Pass-through

LEDs
  • Power
  • WLAN (Wireless Connection)

Power
  • DC 12V

Operating Temperature
  • 30° to 104° F (0° to 40° C)

Operating Humidity
  • 10% to 95% non-condensing
Certifications
  • FCC
  • IC
  • Wi-Fi
  • IPv6
Dimensions (L x W x H)
  • 8.4" x 6.3" x 1.4" (21.3cm x 16cm x 3.6cm)

Weight
  • 0.75 lb (341.5 g)

All references to speed are for comparison purposes only. Product specifications, size and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
