Switch Unmanaged 16 porte 10/100Mbps

DES-1016D

  • Stato del prodotto: In produzione
The DES-1016D 16-Port Fast Ethernet Unmanaged Desktop Switch is designed to enhance workgroup performance while providing a high level of flexibility. Powerful yet easy to use, this device allows users to simply plug any port to either a 10Mbps or 100Mbps network to multiply bandwidths, boost response time and satisfy heavy load demands.

Download the datasheet.

Elenco negozi

The DES-1016D 16-Port Fast Ethernet Unmanaged Desktop Switch is designed to enhance workgroup performance while providing a high level of flexibility. Powerful yet easy to use, this device allows users to simply plug any port to either a 10Mbps or 100Mbps network to multiply bandwidths, boost response time and satisfy heavy load demands.

Ideal for Basic Networking Tasks

With the D-Link DES-1016D, you can easily expand your network by adding more computers or devices with speeds up to 200 Mbps per port in full-duplex mode.

Auto-Sensing 10/100 Ports

The DES-1016D use auto-sensing 10/100 Mbps ports, allowing a small workgroup to flexibly connect to 10 or 100 Mbps devices to create an integrated network. Each port automatically adjusts for straight-through or crossover cables to make the right link.

Flow Control for Secure Transmission

802.3x flow control on each port minimizes dropped packets when the port’s receiving buffer is full.

Quality of Service (QoS)

The switches provide 802.1p priority queues for QoS, allowing users to run bandwidth-sensitive applications such as multimedia and VoIP Internet telephone without data flow bottlenecks that can degrade the quality of the network connection.

Save on Energy Costs

The switches support IEEE802.3az EEE which enables the switches to reduce power consumption when the switches are at low utilization, allowing users to save on power usage and costs. During these periods of low utilization, the switches can enter a low-power state and use up less power than regular operations.

Technical Specifications

Caratteristiche Principali
  • Switch Layer 2
  • 16 porte NWay 10/100Mbps (RJ-45)
  • Standard IEEE 802.3 10BASE-T
  • Standard IEEE 802.3u 100BASE-TX
  • Standard IEEE 802.3x controllo di flusso in full-duplex
  • Funzione di auto-negoziazione della velocità per tutte le porte
  • Funzionalità MDI/MDIX per tutte le porte
  • Modalità Back-pressure in half-duplex
  • Supporto full/half duplex per ogni porta
  • Auto apprendimento della configurazione di rete
  • Auto correzione dell'inversione di polarità RX


Funzionalità
  • Metodo switching : Store and Forward
  • Modalità Wire-speed
  • Tabella indirizzi MAC : 8K per dispositivo
  • 2Mb RAM buffer allocato dinamicamente per ogni porta
  • Switch back-plane : 4.8Gbps in modalità full-duplex
  • Percentuali filtraggio/inoltro dei pacchetti Ethernet : 14,880 pps per porta
  • Percentuali filtraggio/inoltro dei pacchetti Fast Ethernet : 148,800 pps per porta
  • Design Fan-less (senza ventola di raffreddamento)
  • Desktop Sized (piccole dimensioni da scrivania)
  • LED diagnostici per le porte (Speed 10/100Mbps) e per l'apparato (Power)


Certificazioni
  • FCC Classe A
  • VCCI Classe A
  • CE
  • C-Tick
  • BCIQ
  • CUL


Garanzia

  • 2 anni
Versione Data Tipo Dimensioni file
Datasheet (English) - PDF 0.13mb Download
Versione Descrizione Data Tipo Dimensioni file
Manual Manual 01/09/1999 PDF 1.10mb Download
Versione Descrizione Data Tipo Dimensioni file
Quick Installation Guide (English) - PDF 0.40mb Download
Versione Descrizione Data
DEU_AD_F1_CE_Doc CE Declaration 28/08/2012 Download
DEU_AD_E1_CE_Doc CE Declaration 12/07/2010 Download
DEU_AD_D4_CE_Doc CE Declaration 02/07/2009 Download
