Sharecenter™ 2-Bay Network Storage Enclosure

DNS-325, DNS-325-1TB, DNS-325-2TB

  • Product Status: Phased Out
The D-Link ShareCenter 2-Bay Network Storage Enclosure supports up to 8TB of capacity allowing everyone on your network to back up and share their documents, music, photos, and videos to a central location. With a 1.2GHz CPU and applications for streaming and sharing, the DNS-325 is ideal for media users.

Download the datasheet.

Partner üzleteink
RAID 1 Technology
RAID 1 is like a backup for your backup. It causes the drives in your storage device to mirror each other, so if one drive fails the unaffected drive will continue to function until the failed one is replaced.

Web File Server and FTP Server
The DNS-325 includes a built-in Web File server and FTP server to make accessing files remotely, over the Internet, a breeze. The FTP server will come in handy when you need to share a file too big to e-mail to a friend.

DLNA Server
This ShareCenter device has a built-in media server that can stream your photos, music and videos to all of the computers in your home and to compatible media players like Boxee Box, Xbox and PlayStation 3 so you can enjoy it all on your TV.

10/100/1000 Gigabit Port
The 10/100/1000 Gigabit Ethernet port gives you blazing fast speeds so you can back up and access your data without the wait.

Cooling Fan
There’s no overheating in this device’s future. It comes with a quiet, built-in cooling fan that only comes on when needed, saving you power and money.

D-Link Easy Search Utility
The D-Link Easy Search Utility allows you to locate your ShareCenter from anywhere on the network and map your network drive so it will conveniently appear in "My Computer" on your PC.

Backup Software
The included feature-rich backup software allows you to create schedules and rules including full or incremental backups.

Easy Setup
Not quite the handyman? That’s ok. You can insert an additional hard drive without using any tools or attaching any cables. You can insert up to 2 SATA hard drives without using any tools or attaching any cables.

D-Link Green
This product allows hard drives to enter sleep mode when not in use to conserve electricity and prolong the life of the hard disk. Plus, it uses recyclable packaging and complies with the European Union’s RoHS directive.

USB Print Server Port
This storage device can also serve as a USB print server, allowing you to share a single USB printer over your network. The USB port can also support a Universal Power Supply (UPS) monitor that supports ‘smart’ signaling over a USB connection. If a power outage were to occur, the compatible UPS monitor would allow the UPS unit to safely shut down the ShareCenter.

AjaXplorer
AjaXplorer is a file explorer that allows you to remotely manage your files using a web browser. Stay protected - anywhere, anytime.

Mac Friendly
Not to worry, Mac users! ShareCenter can back up your data regardless of your computer's operating system (Windows, Mac or Linux)

Support for:
  • AFP (Mac)
  • Time Machine (Mac)
  • NFS (Linux)

Photo Center
Are you tired of sending individual photos through email? The ShareCenter Photo Center app provides a convenient interface from which you can create and share photo albums with friends and family easily over the web.

Audio Streamer
Stream music throughout your home. The Audio Streamer allows you to transmit multiple streams of audio to any device with an Internet connection, whether it be your computer, TV or tablet.

Logitech Squeeze Center
Connect your Logitech Media Squeezebox player to your ShareCenter and play endless hours of music files stored on your deivce.

Blog
Create and host your own customized Blog from your ShareCenter device. Access and comment on it from anywhere you have an Internet connection.


A termék tényleges kinézete eltérhet az oldalon látható képtől.

Related Products

Boxee Box
DSM-380
Tudj meg többet!
Éjjellátó Cloud Kamera SD kártyával
DCS-942L
Tudj meg többet!
Whole Home Router 1000
DIR-645
Tudj meg többet!
PTZ Cloud Kamera
DCS-5222L
Tudj meg többet!

Technical Specifications

Models

  • DNS-325
  • DNS-325-1TB (includes preinstalled 1 x 1TB hard disk drive)
  • DNS-325-2TB (includes preinstalled 1 x 2TB hard disk drive)



Standards

  • IEEE 802.3 10Base-T Ethernet
  • IEEE 802.3u 100Base-TX Fast Ethernet
  • IEEE 802.3ab 1000Base-T Gigabit Ethernet



Support Hard Drive Type1

  • 3.5" Internal SATA Hard Drive, up to 4TB2



Ports

  • 1 x 10/100/1000 Gigabit Ethernet
  • 1 USB Port
  • Power



Drive Management

  • Four different hard disk drive configurations (RAID 0, 1, JBOD, standard)
  • Drive status with e-mail alerts
  • Drive quotas
  • Power management



Device Management

  • Internet Explorer® v6 or other Java-enabled browsers



LEDs

  • Power
  • LAN
  • HDD 1
  • HDD 2



Certifications

  • FCC Class B
  • CE



Power Supply

  • External power supply
  • DC 12V / 4A switching



Power Consumption

  • Normal mode: 21.04 W
  • Sleep mode: 10.45 W



Power Management

  • Power saving
  • Schedule power Off
  • Auto power recovery support



Operating Temperature

  • 0º to 40º C (30º to 104º F)



Operating Humidity

  • 10% to 95% Non-Condensing



Dimensions (W x D x H)

  • Item: 104mm x 198mm x 132mm (4.1” x 7.8” x 5.2”)



Weight

  • 1.225 kg



Multilingual Support

  • Samba: Unicode
  • FTP Client/ iTunes Server: Unicode , Croatian, Cyrillic (Kyrgyz Republic), Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Norwegian, Polish, Portuguese, Romanian, Russian, Simplified Chinese, Slovenian, Spanish, Swedish, Traditional Chinese, Turkish, Korean, Hebrew

Enhanced RAID Roaming upgrade compatibility

New destination model
DNS-320 A2 DNS-325 DNS-345 DNS-320L
DNS-320LW
Old
source
model
DNS-320 A2
DNS-325 (EXT3)
DNS-325 (EXT4)
DNS-345
DNS-320L
DNS-320LW


1 Hard drives only included for DNS-325 1TB (1 x 1TB) and DNS-325 2TB (1 x 2TB). RAID 1 mirroring requires the use of two internal SATA drives. To avoid data incompatibility in RAID 1 operation, use SATA drives from the same manufacturer. Formatted drive capacity for RAID 1 operation is dependent on the drive capacity of the lowest-sized drive. May not work with older generation SATA drives. For a list of SATA drives that have been tested to work with the ShareCenter™, visit D-Link support websites.
2 Maximum HDD capacity supported may increase in future depending on firmware upgrades.

Actual product appearance may differ from the image displayed on this page

FAQ

  • Honnan tudhatom, hogy a DNS-320/320L/323/325/327L szerveremen meghibásodott a merevlemez? Read Answer
  • Hogyan állíthatom be a Dinamikus DNS-t a NAS Share Center-en? Read Answer
  • Why can´t I see my files, on the first drive, after adding a second drive in my DNS 320/321/323/325? Read Answer
  • Hogy hozhatok létre felhasználókat NAS szerveremen? Read Answer
Getting started with DNS-325
Version Date Type File Size
Datasheet (English) - PDF 2.04mb Letölt
Storage Product Guide - PDF 2.63mb Letölt
IP Surveillance Guide - PDF 3.58mb Letölt
Version Description Date Type File Size
Product manual Product manual - PDF 8.92mb Letölt
Version Description Date Type File Size
- - PDF 0.88mb Letölt
Ezen D-Link termék tartalmaz harmadik fél által fejlesztett szoftver kódokat, beleértve GNU "Általános Nyilvános Licenc" ("GPL") vagy a GNU "Lazábban Kezelt Általános Nyilvános Licenc" ("LGPL") szoftver kódokat. Amennyiben szükséges, a GPL és LGPL felhasználási feltételei és az információk, amelyek ezen termékben használt GPL és LGPL kódok elérése érdekében szükségesek, az Ön rendelkezésére állnak a következő címen:

http://tsd.dlink.com.tw/GPL.asp

Ezen termékben használt GPL és LGPL kódok GARANCIA NÉLKÜL lettek terjesztve, és azok egy vagy több szerző szerzői jogi védelme alatt állnak. Részletekért tekintse meg ezen termék GPL és LGPL kódját és a GPL és LGPL felhasználási feltételeit.
Version Description Date
Firmware: v1.05 build 04 1.05b04 Firmware: v1.05 build 04 2016.11.18. Letölt
Firmware: v1.03 build 03 1.03 b03 Firmware: v1.03 build 03 - Letölt
Version Description Date
My Surveillance addon My Surveillance addon 2016.03.14. Letölt
Software: MyDlink Cloud Package v2.38 2.38

Software: MyDlink Cloud Package v2.38

2014.07.28. Letölt
Software: Yahoo Widget 2.01 2.01 Software: Yahoo Widget 2.01 2012.10.01. Letölt
Software: Audio streamer Package 2.01 2.01 Software: Audio streamer Package 2.01 2012.08.30. Letölt
Software: GPL Code v1.00 1.00 Software: GPL Code v1.00 2012.08.30. Letölt
Software: Amule Package 2.01 2.01 Software: Amule Package 2.01 2012.08.03. Letölt
Software: Setup Wizard v1.0.4.3 1.043 Software: Setup Wizard v1.0.4.3 2012.01.10. Letölt
Software: Storage Utility v5 5.000 Software: Storage Utility v5 2011.04.06. Letölt
Software: Ajaxplorer 2.01 2.01 Software: Ajaxplorer 2.01 - Letölt
Software: Blog Package 2.01 2.01 Software: Blog Package 2.01 - Letölt
Software: Photocenter Package v2.01 2.01 Software: Photocenter Package v2.01 - Letölt
Software: PnP X-Treiber v1.00 1.00 Software: PnP X-Treiber v1.00 - Letölt
Software: Squeeze Center Package v2.02 2.02 Software: Squeeze Center Package v2.02 - Letölt
Version Description Date
Hard disk drive compatibility list

Hard disk drive compatibility list

2015.11.23. Letölt
Certificate of Declaration rev. A2 Certificate of Declaration rev. A2 2012.08.20. Letölt
Certificate of Declaration rev. A1 Certificate of Declaration rev. A1 2010.12.15. Letölt
