Wireless N Dual Band PoE Access Point

DAP-2590

  • Product Status: Phased Out

The DAP-2590 is second generation Dual Band Wireless N indoor access point designed specifically for businesses. It’s varied and comprehensive management capabilities ensures that the DAP-2590 meets the needs of almost any business.


Download the datasheet.

List Retailers

Compatibility and performance

With adjustable antennas, the DAP-2590 delivers 300Mbps per band performance

Broadcast 16 independent SSIDs simultaneously

Supports up to 16 SSIDs, 8 per Band, including station isolation

Performance and Compatibility

The DAP-2590 is a second generation Dual-Band Wireless N indoor access point designed specifically for businesses. It’s varied and comprehensive management capabilities ensures that the DAP-2590 meets the needs of almost any business.

Simultaneous Dual-Band Wireless

Supports up to 300Mbps for the 5Ghz band and up to 300Mbps for the 2.4Ghz band

Smart Design

The DAP-2590 has a wireless scheduler feature, which turns off wireless functionality when it isn’t needed, saving power and increasing network security.

Related Products

Web Smart 24-Port PoE 10/100 + (4) 1000BASE-T Ports + 2 Combo Ports Switch
DES-1228P
Find out more
24-Port xStack Gigabit L2+ Stackable Managed PoE Switch
DGS-3426P
Find out more

Technical Specifications

Standards
  • IEEE Draft 2.0 802.11n
  • IEEE 802.11a
  • IEEE 802.11g
  • IEEE 802.3ab
  • IEEE 802.3af
  • IEEE 802.3u
  • IEEE 802.3

Network Management
  • Command Line Interface: Telnet / Secure (SSH) Telnet
  • Web Browser interface: HTTP / Secure HTTP (HTTPS)
  • SNMP Support: D-View Module / Private MIB
  • AP Manager II

Security
  • WPA™-Personal
  • WPA™-Enterprise
  • WPA2™-Personal
  • WPA2™-Enterprise
  • 64/128-bit WEP
  • SSID Broadcast Disable
  • MAC Address Access Control

Wireless Frequency Range
  • 2.4GHz (2.4GHz to 2.4835GHz)
  • 5GHz (5.15GHz to 5.35GHz, 5.47GHz to 5.85GHz)

Operating Modes
  • Access Point (AP)
  • WDS with AP
  • WDS/Bridge (No AP Broadcast)
  • Wireless Client

LEDs
  • Power
  • 5GHz
  • LAN
  • 2.4GHz

Operating Voltage
  • 48VDC +/- 10% for PoE or 5V2.5A

Temperature
  • Operating: 32°F to 104°F (0°C to 40°C)
  • Storing: -4°F to 149°F (-20°C to 65°C)

Humidity
  • Operating: 10% ~ 90% (Non-condensing)
  • Storing: 5% ~ 95% (Non-condensing)

Certifications
  • FCC
  • CE
  • C-Tick
  • IC
  • UL
  • Wi-Fi®

Weight
  • 762g

Dimensions (WxHxD)
  • 6.5” x 1.38” x 7.38”

FAQ

Version Date Type File Size
Datasheet (English) - PDF 4.47mb Download
Version Description Date Type File Size
Manual (English)

Manual (English)

- PDF 3.69mb Download
AP Manager II - User AP Manager II - User Manual (English) - PDF 5.96mb Download
Version Description Date Type File Size
Quick Installation Guide (Multilingual) - PDF 1.91mb Download
This D-Link product includes software code developed by third parties, including software code subject to the GNU General Public License (“GPL”) or GNU Lesser General Public License (“LGPL”). As applicable, the terms of the GPL and LGPL, and information on obtaining access to the GPL code and LGPL code used in this product, are available to you at:

http://tsd.dlink.com.tw/GPL.asp

The GPL code and LGPL code used in this product is distributed WITHOUT ANY WARRANTY and is subject to the copyrights of one or more authors. For details, see the GPL code and the LGPL code for this product and the terms of the GPL and LGPL.
Version Description Date
Firmware 1.25rc056

Firmware

15.5.2013. Download
Firmware 1.20 rc039 Firmware 26.7.2012. Download
Version Description Date
MIB file 1.15 rc012 MIB file 15.8.2011. Download
AP Manager II v 1.13 1.13 r38

AP Manager II v 1.13

Release notes enclosed.

6.1.2011. Download
Version Description Date
CE Declaration - ver A2 CE Declaration - ver A2 (English, French) 21.8.2009. Download
