5-Bay iSCSI SAN Array with 4x1GbE Ports

DSN-1100-10

  • Product Status: Phased Out
D-Link's DSN-1100-10 iSCSI SAN array is an entry-level network storage solution in a 5-bay desktop form factor, ideal for small businesses. The heart of the DSN-1100-10 is a powerful 10Gbit iSCSI System-on-a-Chip (SoC) capable of handling over 80,000 I/OS per second. The DSN-1100-10 supports 10TB of raw capacity using 2TB drives and can be easily implemented as a supplemental backup platform for quick restores, as secondary online storage, or as bandwidth-demanding primary storage for security surveillance and A/V applications.

Download the datasheet.

List Retailers

Related Products

Full HD PoE Day/Night Network Camera
DCS-2210
Find out more
Full HD Wireless Day/Night Network Camera
DCS-2230
Find out more
HD PoE Day/Night Fixed Network Camera
DCS-3112
Find out more
HD WDR PoE Day/Night Fixed Network Camera
DCS-3710
Find out more
Full HD WDR PoE Day/Night Fixed Network Camera
DCS-3716
Find out more

Technical Specifications

Hardware
  • 5 Hard Drive bays for 3.5” SATA Hard Drives of any capacity (HDD not included)
  • Hot swappable drives
  • SATA-II Support
  • Cache memory: 256 MB (upgradeable to 1GB)
  • System memory: 256 MB (upgradeable to 512MB)
  • Compact chassis that fits anywhere

Network
  • 4 Gigabit Ethernet ports with support for link aggregation
  • Support for Jumbo frames and IEEE 802.3ad Link Aggregation
  • IEEE 802.1Q VLAN tagging

Operating Systems
  • Windows Vista® 32-bit & x64 (Ultimate & Enterprise) with Built-in iSCSI initiator
  • Windows Server® 2003 32-bit & x64 SP1 (Standard & Enterprise) with v2.07 iSCSI initiator
  • Windows Server 2003 R2 32-bit & x64 (Standard & Enterprise) with v2.07 iSCSI initiator
  • Windows® XP Pro 32-bit & x64 with v2.07 iSCSI initiator
  • Windows 2000 Advanced Server with v1.6 & v2.01 iSCSI initiator
  • Red Hat® 7.3
  • Red Hat Enterprise AS update 5
  • SuSE Enterprise Server 10.2 32-bit (x86)
  • SuSE® Professional 9.3 32-bit & x64
  • Mac OS® X (10.4 & 10.5)

Storage network management
  • RAID Hard Drive configurations: 0/1/1+0/5
  • Remote monitoring and configuration via SSL
  • CHAP authentication
Version Date Type File Size
Datasheet - PDF 0.66mb Download
Version Description Date Type File Size
Software User’s Guide Software User’s Guide - PDF 5.73mb Download
Hardware Reference Guide Hardware Reference Guide - PDF 3.04mb Download
Version Description Date Type File Size
1.00 Quick Installation Guide 29.9.2009 PDF 0.78mb Download
Version Description Date
Firmware 2.8.2.2 Firmware 11.5.2011 Download
Firmware 2.8.0.48 Firmware 2.12.2010 Download
Version Description Date
DEU_Interoperability_Matrix_RevA Interoperability Matrix 10.5.2011 Download
Declaration of conformity Declaration of conformity 2.10.2009 Download
