Cloud Gigabit Router AC1750

DIR-865L

  • Product Status: Phased Out

The Cloud Gigabit Router AC1750 creates a blazing fast home network that connects all of your computers and mobile devices to your broadband Internet connection, 6x faster than the previous standard. Concurrent dualband 802.11ac brings you the future of high-bandwidth wireless connectivity allowing you to stream HD video, make Internet calls, and surf the Internet from every corner of your home without interruption.


Download the datasheet.

List Retailers

Upgrade to Wireless AC Performance

The Cloud Gigabit Router AC1750 creates a blazing fast home network that connects all of your computers and mobile devices to your broadband Internet connection, 6x faster than the previous standard. Concurrent dualband 802.11ac brings you the future of high-bandwidth wireless connectivity allowing you to stream HD video, make Internet calls, and surf the Internet from every corner of your home without interruption. The Cloud Gigabit Router AC1750 is mydlink™ Cloud enabled, so you can effortlessly access and view your network no matter where you are. This router is also backwards compatible with earlier wireless standards.

Fast and reliable home networking

This router creates the fastest home network possible today connecting all of your computers and mobile devices to your broadband Internet connection. Concurrent dualband 802.11ac brings you the future of high-bandwidth wireless connectivity allowing you to stream HD video, make Internet calls, and surf the Internet from every corner of your home without interruption. Gigabit Ethernet ports provide high-speed wired connections for up to four PCs or other devices. It’s easy to-use, and comes IPv6-ready for a reliable network today and tomorrow.



Greater coverage and speeds with Wireless AC

This router uses the latest Wireless AC Technology, which can provide transfer rates of up to 1.3Gbps **(1300AC + 450N). Faster gigabit wireless speeds allow you to download content and synch files 6 times faster than the previous standard and provide you with whole home coverage. The router operates on both the 2.4 GHz band and 5 GHz wireless bands at the same time using concurrent dualband technology and six internal antennas. This allows you to browse the web, chat and email using the 2.4 GHz band, while simultaneously streaming digital media, playing online games, or making Internet phone calls on the 5 GHz band.

Stay informed and protected with mydlink™ Cloud Services

This router gives you complete control by allowing you to monitor who is connecting to your network, which sites they are visiting and block unwanted visitors. By downloading the free mydlink™ app you can monitor your home network remotely.

Share and stream files with SharePort™ Technology

Connect a USB storage device to your Cloud Gigabit Router AC 1750 to create a shared storage space, making it easy to access and share files between computers and devices connected to your network. Plug in a USB hard drive to stream your library of videos and music to your laptop. Plus, the SharePort™ Mobile app for iOS and Android™ devices allows you to back up photos and videos stored on your device. You can even customise your shared storage space by creating separate accounts to control access to the USB drive, so you can share your music with everyone but keep your personal files private. This Cloud Router can also be used as a media server for your home to stream media stored on your USB storage drive to any DLNA compliant player like the Boxee Box by D-Link.



** Maximum wireless signal rate derived from IEEE standard 802.11ac (draft) specifications which are subject to change. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate. Environmental factors will adversely affect wireless signal range.

Product Awards

PC Welt
The D-Link DIR-865L has reached the top position:it offers an optimal mix of high speed,a lot of functions and is energy saving during operation.

Related Products

Wireless AC Dualband USB Adapter
DWA-182
Find out more

Technical Specifications

Device interfaces

  • 802.11 a/b/g/n/ac Wireless LAN
  • Four 10/100/1000 Gigabit LAN ports
  • 10/100/1000 Gigabit WAN port
  • USB 2.0 port



Standards

  • IEEE 802.11ac (draft)
  • IEEE 802.11n
  • IEEE 802.11g
  • IEEE 802.11b
  • IEEE 802.11a
  • IEEE 802.3
  • IEEE 802.3u



Antenna Type

  • 6x internal antennas with beamforming technology



Minimum System Requirements

  • Windows 7/Vista/XP SP3 or Mac OS X 10.4 or higher Microsoft Internet Explorer 6 or higher, Firefox 1.5 or higher, or other Java-enabled browser
  • CD-ROM
  • Ethernet network interface
  • Cable or DSL modem
  • Subscription with an Internet Service Provider



Advanced Features

  • Guest Zone
  • Web file access
  • Multi-language Web Setup Wizard
  • Green Ethernet
  • DLNA Media server support
  • Dual Active Firewall:
  • Network Address Translation (NAT)
  • Stateful Packet Inspection (SPI)
  • VPN passthrough/multi-session PPTP/L2TP/IPSec



mydlink™ Features

  • Remote Management
  • View current upload/download bandwidth
  • View currently connected clients
  • View web browsing history per client
  • Block/unblock client network access
  • Manage wireless network details
  • Accessible through a web browser or iOS or Android™ mobile app



Mobile App Support

  • mydlink™ Lite
  • SharePort™ Mobile
  • QRS Mobile



Wireless Security

  • WPA & WPA2 (Wi-Fi Protected Access)
  • Wi-Fi Protected Setup (WPS) PIN/PBC



Dimensions

  • 32 x 167 x 240 mm (1.26 x 6.57 x 9.45 inches) (without pedestal)
  • 70 x 167 x 252 mm (2.76 x 6.57 x 9.92 inches) (with pedestal)



Weight

  • 0.55kg



Power

  • Input: 100 to 240 V AC, 50/60 Hz
  • Output: 12 V DC, 3 A



Temperature

  • Operating: 0 to 40 °C (32 to 104 °F)
  • Storage: -20 to 65 °C (-4 to 149 °F)



Humidity

  • Operating: 0% to 90% non-condensing
  • Storage: 5% to 95% non-condensing



Certifications

  • FCC Class B
  • CE Class B
  • C-Tick
  • DLNA
  • IPv6 Ready
  • Wi-Fi Certified
  • Wi-Fi Protected Setup (WPS)
  • Wi-Fi Multimedia (WMM)
  • Compatible with Windows



UPC codes:

  • 790069380198(/EU)
  • 790069380181(/UK)



Product:

  • Dimensions: 70 x 167 x 252 mm.
  • Weight: 0.55kg



Giftbox:

  • Dimensions: 245 x 285 x 87 mm.
  • Weight: 1.2kg

FAQ

  • How do I configure MAC filtering on my DIR/WBR series router? Read Answer
  • What can I do if I have Java installation issues on Mac OS? Read Answer
How to connect to wireless in Windows 8
How to connect to wireless in Windows 7
How to download and use the QRS Mobile App for your iPhone/iPad
How to add your router to your Mydlink account
How to use the Mydlink SharePort app on your iPhone/iPad
How to connect to wireless using an iPhone
How to configure SharePort Mobile
How to change router password
How to change your routers IP address
How to disable UPnP on your router
Version Date Type File Size
Datasheet (English) - PDF 2.35mb Download
Version Description Date Type File Size
Manual (English) Manual (English) - PDF 8.34mb Download
Version Description Date Type File Size
1.00

Quick Installation Guide (English)

- PDF 0.89mb Download
This D-Link product includes software code developed by third parties, including software code subject to the GNU General Public License (“GPL”) or GNU Lesser General Public License (“LGPL”). As applicable, the terms of the GPL and LGPL, and information on obtaining access to the GPL code and LGPL code used in this product, are available to you at:

http://tsd.dlink.com.tw/GPL.asp

The GPL code and LGPL code used in this product is distributed WITHOUT ANY WARRANTY and is subject to the copyrights of one or more authors. For details, see the GPL code and the LGPL code for this product and the terms of the GPL and LGPL.
Version Description Date
Firmware Fixes Security vulnerabilities 1.08b01 Firmware
Fixes Security vulnerabilities
17.6.2015 Download
Version Description Date
SharePort Plus for Windows SharePort Plus for Windows 11.12.2015 Download
SharePort Plus for Mac 4.40 SharePort Plus for Mac 10.11.2014 Download
GPL Code GPL Code - Download
Version Description Date
DEU_CE_Declaration_RevA CE Declaration - ver A1 (English, French, Spanish, Portuguese) 2.7.2012 Download
