Wireless N Home Network Camera

DCS-930

  • Product Status: Phased Out
The DCS-930 is a unique and versatile surveillance solution for your home or small office. Unlike a traditional webcam, the DCS-930 is a complete system with a built-in CPU and web server that transmits high quality video images and audio for security and surveillance. Simple installation and an intuitive web-based interface offer easy integration with your Ethernet or 802.11n wireless network. The DCS-930 also comes with remote monitoring and motion detection features for a complete and cost-effective home security solution.
List Retailers
  • Wireless N technology for a flawless connection anywhere in your home
  • High light sensitivity (1 Lux) for use in low light conditions
  • Motion-triggered alerts by email
  • Built-in microphone
  • Wireless security at the touch of a button with Wi-Fi Protected Setup (WPS)
  • Dynamic DNS support to easily access your camera from anywhere in the Internet

The DCS-930 is a unique and versatile surveillance solution for your home or small office. Unlike a traditional webcam, the DCS-930 is a complete system with a built-in CPU and web server that transmits high quality video images and audio for security and surveillance. Simple installation and an intuitive web-based interface offer easy integration with your Ethernet or 802.11n wireless network. The DCS-930 also comes with remote monitoring and motion detection features for a complete and cost-effective home security solution.

Wireless-N connectivity

The DCS-930 includes 802.11n wireless for fast and easy integration into your existing network environment. Wireless N allows you to stream high-quality video to remote sites over the Internet. A Site Survey feature also allows you to view and connect to nearby wireless networks with ease. The DCS-930 includes a standard Ethernet port for connections to traditional wired networks.

Easy to configure and operate

This network camera supports the Universal Plug-n-Play feature, which allows computers running on Windows XP/Vista/7 to automatically recognize the camera and add it to the network. Sign up with one of the free Dynamic DNS services available on the web to assign a name and domain to the camera (e.g. mycamera.dlinkddns.com), and remotely access the camera without having to remember the IP address. You may also view up to 32 cameras from a central location using the included D-ViewCam software. D-ViewCam has a robust set of features including automated e-mail alerts which can instantly inform users of suspicious or unusual activities.


Actual product appearance may differ from the image displayed on this page

Technical Specifications

Camera
  • 1/5 inch color VGA CMOS Sensor
  • Minimum illumination 1 lux @ F2.8
  • Auto Gain Control (AGC)
  • Auto White Balance (AWB)
  • Auto Electronic Shutter (AES)
  • Lens: focal length: 2P, 5.01mm, F2.8
  • 4x digital zoom for close-ups*

Network
  • 10/100Base-TX Ethernet port
  • 802.11b/g/n Wireless LAN with WEP/WPA/WPA2 security
  • Wi-Fi Protected Setup (WPS) for easy wireless encryption setting
  • Dynamic DNS support (Dyndns and D-Link)
  • UPnP™support
  • Web-based configuration

Audio & Video
  • Built-in microphone
  • MJPEG motion image compression
  • JPEG for still image
  • Flip and mirror
  • Time stamp and text overlay
  • Adjustable image size and quality

Monitoring and recording
  • Remote recording using a web browser: no software required
  • Motion triggered video recording and e-mail alerts
  • D-ViewCam surveillance software included
Version Date Type File Size
Datasheet - PDF 0.52mb Download
Version Description Date Type File Size
User Manual User Manual - PDF 4.81mb Download
Version Description Date Type File Size
1.00 Quick instillation guide (English) 21-05-2010 PDF 0.54mb Download
This D-Link product includes software code developed by third parties, including software code subject to the GNU General Public License (“GPL”) or GNU Lesser General Public License (“LGPL”). As applicable, the terms of the GPL and LGPL, and information on obtaining access to the GPL code and LGPL code used in this product, are available to you at:

http://tsd.dlink.com.tw/GPL.asp

The GPL code and LGPL code used in this product is distributed WITHOUT ANY WARRANTY and is subject to the copyrights of one or more authors. For details, see the GPL code and the LGPL code for this product and the terms of the GPL and LGPL.
Version Description Date
Firmware 1.03.4 Firmware 09-05-2011 Download
Version Description Date
Install Wizard 1.01 Install Wizard 19-04-2011 Download
Version Description Date
DNR_2020_04P_Cam_Support_list DNR-2020-04P Camera Support List 22-09-2016 Download
DEU_CE_Declaration_RevA Declaration of conformity 29-09-2011 Download
