140W redundantes externes Netzteil

DPS-500

  • Produkt Status: Abgekündigt (EOL)
Externes Netzteil mit 140 Watt zur redundanten Stromversorgung eines D-Link Switches.

Die Abbildung kann vom tatsächlichen Produkt abweichen.
24-Port xStack L3 Gigabit Stackable Managed Switch mit optionalen 10 Gigabit Uplinks
Find out more

Technical Specifications

Input Voltage Range
  • 90VAC to 264VAC

Input Frequency Range
  • 47 Hz to 63 Hz

AC Input Current
  • 4A max. @ 115VAC
  • 2A max. @ 230VAC

Maximum In-rush Current
  • 30A max. @ 115VAC (at 25˚ C ambient cold start)
  • 50A max. @ 230VAC (at 25˚ C ambient cold start)

Leakage Current
  • 3.5mA max.

Output Voltage
  • +5VDC
  • +12VDC

Minimum Load Current
  • 0A (+5VDC output)
  • 0A (+12VDC output)

Maximum Load Current
  • 1.5A (+5VDC output)
  • 13A (+12VDC output)

Total Output Power
  • 140 watts

Efficiency
  • 80% min. @ max.

Over Voltage Protection
  • 13.5V to 17V

AC Power Good (PWR-GOOD) Signal Required
  • +5V
  • +12V

LED Status
  • On: RPS good
  • Off: RPS failed

Dimensions
  • 196mm (L) x 195mm (W) x 50mm (H)

Weight
  • 1.5 kg

Operating Altitude
  • 3,000 m (10,000 feet) max.

Storage Altitude
  • 12,000 m (40,000 feet) max.

Operating Temperature
  • 0˚ to 50˚C

Storage Temperature
  • -20˚ to 80˚C

Operating Humidity
  • 5% to 95% RH

Storage Humidity
  • 5% to 95% RH

Safety Standards
  • UL 60950 3rd Edition
  • CSA 22.2 No.234
  • EN 60 950

Safety Approvals
  • UL
  • CSA

EMI
  • FCC Class B

MTBF
  • 598,552hours
This product was phased out on: 03.02.2017
