JustConnect Multifunctional Network Video Recorder

DNR-2060-08P

  • Dostupnost produktu (Revision A): End of Life

The DNR-2060-08P JustConnect Network Video Recorder is a comprehensive standalone network video display, storage, and management solution providing reliable high quality monitoring for IP-based security systems. The DNR-2060-08P enables simultaneous recording and remote access to recorded videos as well as live view. Controlling the DNR-2060-08P is exceptionally easy using conventional front panel controls, or with an optional keypad and mouse, or remote control handset. The highly flexible, simple-to-configure, and manage make the DNR-2060-08P a cost-effective upgrade addition to your security and surveillance infrastructure.

Maximising the potential

The latest multi-megapixel resolution cameras demand a new generation of network recording solutions. The DNR-2060-08P exceeds these demands and adds reliability, scalability, flexibility, ease of use and competitive pricing.

Robust Management Software

The standalone DNR-2060-08P includes a complete surveillance software package that enables you to view, manage, store, record, and search through footage from up to eight cameras in a central location, without the need of a computer. Recordings and e-mail alerts can be triggered through motion detection or events triggered by digital input devices, keeping administrators informed of any unusual activity.

Connectivity

The DNR-2060-08P has eight built-in 802.3at compliant PoE+ ports that simplifies camera installation by providing both power and network connectivity through a simple cable. Not only does this save overall installation cost by eliminating the need to install separate electrical wiring and power outlet, PoE+ allows you to power even the most demanding cameras. In addition, the included digital input and output connector enables further integration to external devices such as switches and alarm relays.

Ocenění produktu

Business Computing World
D-Link’s DNR-2060-08P JustConnect Network Video Recorder is designed to bridge the gap between still very popular analogue CCTV and digital IP surveillance systems, the aim being to make IP systems as easy to install and use as analogue.

Technické specifikace produktu

Channel Number
8 channels
Compression Format
H.264

MJPEG
Video Output
HDMI

VGA
Display Mode
1, 4, 8 split screen
Auto Scan
Supported
PTZ Control
Supported
Auto Pan/Petrol
Supported
Audio
1-way
Recording Type
Digital Input

Edge Motion Detection by Camera

Manual

Motion Event

Schedule
Pre-Recording Period
70 seconds
Post-Recording Period
70 seconds
Audio Recording
Supported
Auto/Scheduled Recycling
Supported
Simultaneous Playback
8 channels
Video Control
Play, stop, pause, forward, backward, next, previous
Digital Zoom
4X
Audio Control
Supported
Video Search
Camera

Event

Text

Time
Video Export Format
AVI

DRV

RAW
Image Export File Format
JPG
Tamper-Proof (Digital Watermark)
Supported
I/O Control
Supported
Event to E-mail
Supported
Event to Alarm
Supported
Event by Signal Lost
Supported
Event by Disk Full
Supported
Client Viewer
JustConnect+ App

Web browser
Remote View
Supported
Max Concurrent Channel per Client
8
Playback Viewer
Playback manager via browser
Number of E-Map Layer
1
E-Map Image Format
JPG
Supported Camera
D-Link
Number of HDD Bay
6
HDD Configuration
Single
Network Interface
1 x Gigabit port

8 x 802.3at Fast Ethernet ports
PoE support
802.3at
Backup Options
eSATA

USB
Front Panel Control
Supported
Auto Boot-Up (Power Recovered)
Supported
This product was phased out on: 26/07/2017
This product's last date of support is on: 26/07/2019
