Wireless N 150 PCI Adapter

DWA-525

  • Product Status: Phased Out
Connect your desktop computer to a high-speed Wi-Fi network using the D-Link Wireless N 150 Desktop PCI Adapter to experience faster file transfers and browse the Internet from greater distances across your home than pervious-generation Wireless G technology. Upgrading your computer with the Wireless N 150 Desktop PCI Adapter delivers better wireless performance and faster connection to a high-speed wireless network.

Download de datasheet.

Alle Verkooppunten

The DWA-525 Wireless N 150 PCI Adapter delivers high performance wireless networking to a desktop PC. Once connected, you can share a high-speed Internet connection while also having access to shared documents, music, and photos on your network.

  • Wireless N 150 technology: up to 150 Mbps wireless speed with improved coverage and virtually no dead spots
  • Compatible with newer Wireless N and widespread Wireless G technologies
  • Support for Windows 7/VISTA/XP/2000 Operating Systems
  • Certified for Wi-Fi Protected Setup™ (WPS)
  • Low-profile bracket supplied
  • Quick set-up wizard in 18 languages

The DWA-525 Wireless N 150 PCI Adapter delivers high performance wireless networking to a desktop PC. Once connected, you can share a high-speed Internet connection while also having access to shared documents, music, and photos on your network.

Why N 150?
Based on Wireless N technology with a single antenna, the DWA-525 achieves wireless speeds of up to 150 Mbps and extended coverage with virtually no dead spots1. It is compatible with newer Wireless N and widespread Wireless G technologies and will work with Wi-Fi certified routers or Access Points of any brand.

Easy to install and connect
D-Link’s Quick Setup Wizard available in 18 languages ensures an easy setup process so you can get connected quickly. Just insert the product CD and follow the interactive guide to install drivers and configure wireless security. It’s easy with Wi-Fi Protected Setup (WPS), which works by clicking a button and automatically creates a secure wireless connection to your router. The Wireless Manager included with this product keeps track of all of the most frequently accessed networks.

1 Maximum wireless signal rate derived from IEEE standard 802.11g specifications. Actual data throughput may vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead, may lower actual data throughput rate. Environmental factors may adversely affect wireless signal range.

Actual product appearance may differ from the image displayed on this page

Gerelateerde Producten

Wireless N Range Extender
DAP-1360
Meer lezen
4G LTE Router
DWR-921
Meer lezen
Wireless N 300 Home Cloud Router
DIR-605L
Meer lezen
N300 Wi Fi Range Extender
DAP-1330
Meer lezen
N300 Wi-Fi Range Extender with Power Passthrough
DAP-1365
Meer lezen

Technical Specifications

Hardware
  • 32-bit PCI local bus
  • Low-profile bracket included
  • Detachable 2 dBi dipole antenna

Wireless
  • Up to 150 Mbps wireless speeds
  • 2.4GHz frequency band
  • Compatible with 802.11g and 802.11n wireless networks

Operating Systems
  • Windows 2000 (SP4)
  • Windows XP (SP2 and above)
  • Windows Vista (32 or 64-bit)
  • Windows 7 (32 or 64-bit)

Security
  • Strong WPA/WPA2 data encryption security
  • Wireless Protect Setup (WPS): wireless encryption at the click of a button

Configuration/Management
  • Quick setup wizard in 18 languages
  • D-Link Wireless Manager for easy access to frequently accessed networks

FAQ

  • How do I find my IP address in Windows Vista or Windows 7 Lees antwoord
  • How do I install my Wireless Adapter correctly in Windows Lees antwoord
How to connect to wireless in Windows 8
How to connect to wireless in Windows 7
Versie Datum Type Bestandsgrootte
Blad in het Engels - - - Download
Versie Beschrijving Datum Type Bestandsgrootte
Handleiding in het Engels Handleiding in het Engels - - - Download
Handleiding in het Duits Handleiding in het Duits - - - Download
Versie Beschrijving Datum Type Bestandsgrootte
Installatiehandleiding Installatiehandleiding - - - Download
Versie Beschrijving Datum
1.25b03 voor Windows Huidige driver voor Windows XP (32/64 Bit), Vista (32/64 Bit), 7 (32/64 Bit), 8 (32/64 Bit), 8.1 (32/64 Bit), 10 (32/64 Bit) 31/12/2015 Download
Versie Beschrijving Datum
Conformiteitsverlaring Rev.A1 Conformiteitsverlaring Rev.A1 - Download
Conformiteitsverlaring Rev.A2 Conformiteitsverlaring Rev.A2 - Download
